AGLN020V5-QNG68I

The AGLN020V5-QNG68I is an IGLOO nano field programmable gate array (FPGA) from Microchip Technology, offered in a compact 68‑VFQFN exposed pad package. It provides 520 logic elements and 49 general-purpose I/O lines in an industrial‑grade device designed for surface‑mount assembly.

This FPGA is suited to embedded and control designs that require a small-footprint programmable logic element with defined gate and I/O counts, a narrow core voltage range, and an extended operating temperature window.

Key Features

• Core Logic  520 logic elements totaling approximately 20,000 gates to implement glue logic, state machines, and modest combinational/sequential logic functions.
• I/O  49 available I/O pins for connecting peripherals, sensors, and external devices directly to the FPGA fabric.
• Memory  0 total on-chip RAM bits, suitable for designs that use external memory or require logic-only implementations.
• Power  Defined supply voltage range of 1.425 V to 1.575 V for the core, enabling predictable power budgeting around the FPGA core rails.
• Package & Mounting  68‑VFQFN exposed pad (68‑QFN, 8×8) surface-mount package for compact board layouts and thermal pad support.
• Temperature & Grade  Industrial grade with an operating temperature range of −40 °C to 100 °C, appropriate for extended environmental use.

Typical Applications

• Industrial control systems  Use the 520 logic elements and 49 I/O for implementing control logic, interface glue, and signal conditioning in industrial equipment.
• Embedded processing and glue logic  Ideal for designers needing a compact FPGA for bus bridging, protocol conversion, or finite-state control without on-chip RAM.
• Sensor and peripheral interfacing  Leverage the available I/O to gather sensor signals and perform deterministic pre-processing before passing data to a host MCU or ASIC.

Unique Advantages

• Compact, exposed‑pad VFQFN package: Enables dense PCB layouts while providing a thermal pad for heat dissipation in space-constrained designs.
• Clear logic resource sizing: 520 logic elements and ~20,000 gates give predictable capacity for planning and partitioning of logic functions.
• Defined core voltage: A tight 1.425 V to 1.575 V supply window simplifies power-supply design and integration with regulated cores.
• Industrial temperature rating: Rated from −40 °C to 100 °C to meet environmental requirements for many industrial applications.
• No on‑chip RAM: The absence of embedded RAM focuses the device on logic-centric tasks and makes external memory choices explicit in system design.

Why Choose AGLN020V5-QNG68I?

The AGLN020V5-QNG68I positions itself as a compact, industrial-grade programmable logic option when designers need a defined set of logic resources and I/O in a small surface-mount package. Its combination of 520 logic elements, 49 I/O, and a 68‑VFQFN exposed pad package makes it straightforward to integrate into embedded control, interfacing, and glue-logic roles.

For teams designing cost- and space-sensitive systems that require predictable logic capacity and an industrial temperature range, this IGLOO nano FPGA delivers a clear specification set to aid selection, board layout, and power planning while benefiting from Microchip Technology’s manufacturing pedigree.

Request a quote or submit a parts inquiry to check pricing, availability, and lead times for AGLN020V5-QNG68I.
