AT40K20AL-1BQC

IC FPGA 114 I/O 144LQFP
Part Description

AT40KAL Field Programmable Gate Array (FPGA) IC 114 8192 1024 144-LQFP

Quantity 176 Available (as of May 5, 2026)
Product CategoryField Programmable Gate Array (FPGA)
ManufacturerMicrochip Technology
Manufacturing StatusObsolete
Manufacturer Standard Lead TimeRFQ
Datasheet

Specifications & Environmental

Device Package144-LQFP (20x20)GradeCommercialOperating Temperature0°C – 70°C
Package / Case144-LQFPNumber of I/O114Voltage3 V - 3.6 V
Mounting MethodSurface MountRoHS ComplianceRoHS non-compliantREACH ComplianceREACH Unaffected
Moisture Sensitivity Level3 (168 Hours)Number of LABs/CLBs1024Number of Logic Elements/Cells1024
Number of Gates30000ECCN3A991DHTS Code8542.39.0001
QualificationN/ATotal RAM Bits8192

Overview of AT40K20AL-1BQC – SRAM-based FPGA, 144-LQFP

The AT40K20AL-1BQC is an SRAM-based field programmable gate array (FPGA) in a 144-LQFP surface-mount package optimized for commercial embedded designs. It delivers a balance of reconfigurable logic, on-chip memory, and I/O capacity for applications that require in-system reconfiguration and DSP-style coprocessing.

Built on the AT40KAL family architecture, this device provides 1,024 logic elements, 8,192 bits of distributed SRAM, and 114 I/O pins, with a supply range of 3.0 V to 3.6 V and commercial operating temperature from 0 °C to 70 °C.

Key Features

  • Core Logic 1,024 logic elements (cells) providing approximately 30,000 equivalent gates for implementing combinational and sequential logic.
  • Embedded Memory (FreeRAM) 8,192 bits of distributed 10 ns SRAM supporting single- or dual-port, synchronous/asynchronous configurations for FIFOs, scratch pads and small buffers.
  • I/O and Voltage 114 I/Os with programmable output drive; device supply 3.0 V to 3.6 V and documented 3.3 V operation with 5 V I/O tolerance (per family datasheet information).
  • Clocking and Timing Family-level architecture includes 8 global clocks and low-skew clock distribution features to simplify multi-clock designs and clock domain management.
  • Reconfiguration (Cache Logic) Supports dynamic partial or full in-system reconfiguration capability as described for the AT40KAL family, enabling adaptive designs and on-the-fly updates.
  • Performance Family-level performance characteristics include system speeds to 100 MHz and array multipliers >50 MHz, with 10 ns flexible SRAM timing for high-speed on-chip storage.
  • Package and Mounting 144-LQFP (20 × 20 mm) surface-mount package suitable for standard PCB assembly and compact board-level integration.
  • Compliance and Grade Commercial grade device with RoHS compliance for lead-free assembly processes.

Typical Applications

  • Signal Processing / DSP Coprocessor Implement FIR filters, FFTs, convolution and other arithmetic functions using the device’s distributed SRAM and array multiplier capabilities.
  • Communications Interfaces Use reconfigurable logic and flexible I/O to implement protocol bridging, custom PHY logic or peripheral interfaces in embedded systems.
  • Video and Multimedia Acceleration Offload computation-intensive tasks like DCT and image filtering leveraging on-chip RAM and multiplier-friendly cell interconnect.
  • Embedded Control and Glue Logic Integrate timing-critical control, peripheral management and custom finite-state machines in compact, reprogrammable silicon.

Unique Advantages

  • Reconfigurable In-System Logic: Cache Logic capability enables partial or full dynamic reconfiguration for adaptive designs and fast algorithm updates.
  • Embedded, Fast SRAM: Distributed 10 ns SRAM offers low-latency on-chip memory for buffers, FIFOs and coefficient storage without consuming logic resources.
  • Balanced Integration: Combines a mid-range logic element count with substantial on-chip RAM and 114 I/Os in a compact 144-LQFP package to reduce BOM and board area.
  • Commercial-Grade Reliability: Designed for 0 °C to 70 °C operation and RoHS-compliant manufacturing for standard commercial embedded applications.
  • Voltage Flexibility: 3.0 V to 3.6 V supply with documented 3.3 V operation characteristics and 5 V I/O tolerance for interfacing with a range of board-level devices.

Why Choose AT40K20AL-1BQC?

The AT40K20AL-1BQC positions itself as a flexible, SRAM-based FPGA option for designers who need a reconfigurable coprocessing element with on-chip memory and meaningful I/O density in a compact surface-mount package. Its combination of 1,024 logic elements, 8,192 bits of distributed SRAM and dynamic reconfiguration capability supports iterative development and in-field updates for signal processing, interface logic and embedded acceleration tasks.

This device is well suited to commercial embedded system developers seeking a proven FPGA architecture with documented timing characteristics, RoHS compliance and straightforward PCB integration via a 144-LQFP package.

Request a quote or submit an inquiry to receive pricing, availability and assistance matching the AT40K20AL-1BQC to your design requirements.
