XC4003E-2PQ100I

The XC4003E-2PQ100I is a Field Programmable Gate Array (FPGA) from AMD’s XC4000E/X family, provided in a 100-pin BQFP package and rated for industrial use. It offers a compact, surface-mount package with a mix of logic, embedded memory, and I/O suitable for embedded and industrial applications.

With 238 logic elements, 3,200 bits of on-chip RAM and 77 user I/O pins, this device targets designs that require moderate logic density, substantial I/O count, and operation on a 4.5 V to 5.5 V supply across an extended temperature range.

Key Features

• Core Logic — 238 logic elements provide configurable combinational and sequential logic resources for custom digital functions.
• Configurable Logic Blocks (CLBs) — 100 CLBs for structured implementation of logic partitions and state machines.
• Embedded Memory — 3,200 bits of on-chip RAM for small buffers, FIFOs, and register storage.
• I/O Capacity — 77 general-purpose I/O pins to support parallel interfaces, signal aggregation, and glue-logic tasks.
• Gate Count — Approximately 3,000 gates to characterize device complexity and integration level.
• Power Supply — Single-voltage operation from 4.5 V to 5.5 V compatible with common 5 V systems.
• Package & Mounting — Surface-mount 100-BQFP package; supplier device package listed as 100-PQFP (20×14) for PCB footprint planning.
• Operating Range — Industrial temperature rating from −40 °C to 100 °C for deployment in demanding environments.
• Environmental Compliance — RoHS compliant to support regulatory requirements.

Typical Applications

• Industrial Control — Implement control logic, sequencing, and interface bridging in factory automation and process-control modules where industrial temperature and 5 V supply compatibility are required.
• Embedded Systems — Provide glue logic, peripheral interfaces, and custom state machines for embedded controllers and instrumentation.
• I/O-Intensive Designs — Aggregate sensors, switches, and parallel peripherals using the device’s 77 I/O pins for board-level signal management.

Unique Advantages

• Balanced Logic and Memory — Combination of 238 logic elements and 3,200 bits of RAM enables compact implementations of control, buffering, and sequencing functions without external memory.
• Wide I/O Count — 77 user I/O pins reduce the need for additional interface chips in applications that require many signals.
• Industrial Temperature Rating — −40 °C to 100 °C operation supports deployment in temperature-challenging environments.
• 5 V System Compatibility — 4.5 V to 5.5 V supply range simplifies integration into legacy and industrial power domains.
• Compact Surface-Mount Package — 100-pin BQFP surface-mount package enables dense PCB layouts while preserving access to numerous I/Os.
• Regulatory Compliance — RoHS compliance helps meet environmental and manufacturing requirements.

Why Choose XC4003E-2PQ100I?

The XC4003E-2PQ100I delivers a practical balance of logic resources, embedded RAM, and I/O capacity in a compact, industrial-grade surface-mount package. It is well suited for engineers designing embedded controllers, industrial interface modules, and other systems that require moderate programmable logic, reliable operation across an extended temperature range, and compatibility with 5 V power rails.

As an AMD XC4000E/X-series FPGA, this device provides a straightforward option for designers seeking a verified FPGA building block with clear, countable resources and environmental compliance for long-term deployments.

Request a quote or submit an inquiry today to get pricing and availability for the XC4003E-2PQ100I.
