XC4010E-4BG225C

The XC4010E-4BG225C is a Field Programmable Gate Array (FPGA) from AMD's XC4000E/X family, packaged in a 225-ball BGA. It provides a compact, surface-mount programmable logic solution with a defined set of logic resources, embedded RAM and a high I/O count for commercial-grade digital designs.

With up to 950 logic elements, approximately 0.0128 Mbits of embedded memory, and 160 user I/O pins, this device targets applications that require moderate on-chip logic capacity, flexible I/O, and a standard 5 V supply range for straightforward system integration.

Key Features

• Logic Capacity  Approximately 950 logic elements for implementing combinational and sequential logic functions in a compact FPGA footprint.
• Embedded Memory  Approximately 0.0128 Mbits (12,800 bits) of on-chip RAM suitable for small lookup tables, FIFOs or state storage.
• I/O Density  160 user I/O pins to support multiple parallel interfaces, external peripherals and board-level glue logic.
• Gate Equivalent  Rated at 10,000 gates for sizing designs that require a defined gate-count reference.
• Power  Single supply operation from 4.75 V to 5.25 V to match common 5 V system rails.
• Package & Mounting  225-ball BGA (supplier device package: 225-PBGA, 27×27) in a surface-mount package for compact PCB designs.
• Operating Conditions  Commercial-grade operating temperature range of 0 °C to 85 °C for typical ambient environments.
• RoHS Compliant  Manufactured to meet RoHS environmental requirements.

Typical Applications

• Digital Logic Prototyping  Implement and iterate custom digital logic, state machines and control functions during product development.
• I/O Expansion & Glue Logic  Bridge between multiple peripherals or subsystems using the device's 160 I/O pins to consolidate board-level routing.
• Peripheral Interfacing  Create custom interface logic for sensors, actuators or communication peripherals that require tailored signal handling.
• Embedded Control Functions  Integrate control and sequencing logic for compact systems where a moderate amount of on-chip logic and RAM is sufficient.

Unique Advantages

• Balanced Logic and I/O  A combination of about 950 logic elements and 160 I/O pins enables moderately complex designs without excessive board-level peripherals.
• Simplified Power Integration  Runs from a 4.75 V–5.25 V supply for compatibility with standard 5 V system architectures, reducing power-supply design complexity.
• Compact BGA Package  225-ball BGA (225-PBGA, 27×27) minimizes PCB footprint while providing a high pin count for dense designs.
• Commercial Temperature Rating  Specified 0 °C to 85 °C operation suitable for typical commercial electronics and office-environment products.
• RoHS Compliance  Meets environmental compliance expectations for modern electronic assemblies.
• Manufacturer Backing  Part of AMD's XC4000E/X family, providing continuity for projects that reference this product family.

Why Choose XC4010E-4BG225C?

The XC4010E-4BG225C provides a focused balance of logic resources, embedded memory and a large I/O count in a compact 225-ball BGA package—making it suitable for designers who need moderate on-chip logic capacity and extensive external interfacing on a 5 V platform. Its commercial-grade temperature range and RoHS compliance make it appropriate for a wide range of standard electronics projects.

This device is well suited to teams building prototypes, control logic and interface glue that require predictable resources and a compact footprint, and for procurement where AMD family continuity is a factor in design planning.

Request a quote or contact sales to discuss availability, lead times and pricing for the XC4010E-4BG225C.
