XC4044XL-09HQ240C

The XC4044XL-09HQ240C is a Field Programmable Gate Array (FPGA) IC from AMD's XC4000E/X family. It provides a mid-range programmable logic resource set packaged in a 240-pin BFQFP with an exposed pad for thermal performance.

With 3,800 logic elements, a high I/O count and on-chip RAM, this commercial-grade FPGA is suited to designs that require programmable logic integration, flexible I/O routing and a 3.0–3.6 V supply domain within a 0 °C to 85 °C operating range.

Key Features

• Core Logic  Approximately 3,800 logic elements supporting up to 44,000 gates for implementating combinational and sequential logic.
• Embedded Memory  Approximately 0.05 Mbits (51,200 bits) of on-chip RAM for buffering, state storage and small data structures.
• I/O Density  193 user I/O pins provide extensive external interfacing options for parallel and serial peripherals.
• Package and Mounting  240-BFQFP with exposed pad (supplier package: 240-PQFP, 32×32) in a surface-mount form factor to support compact PCB layouts and thermal transfer.
• Power  Operates from a 3.0 V to 3.6 V supply range to match common digital power rails.
• Operating Range  Commercial temperature rating of 0 °C to 85 °C for standard commercial applications.
• Compliance  RoHS compliant for lead-free PCB assembly and environmental regulatory alignment.

Unique Advantages

• Ample programmable logic: 3,800 logic elements enable mid-range design complexity without external glue logic.
• High I/O capability: 193 I/O pins allow direct interfacing to multiple peripherals and parallel subsystems.
• On-chip RAM: 51,200 bits of embedded memory reduce dependence on external SRAM for small buffers and state machines.
• Thermally conscious package: Exposed pad BFQFP package supports improved heat dissipation in surface-mount assemblies.
• Standard commercial grade: 0 °C to 85 °C rating and 3.0–3.6 V supply make it suitable for a wide range of commercial electronics.
• Regulatory alignment: RoHS compliance supports lead-free manufacturing workflows.

Why Choose XC4044XL-09HQ240C?

The XC4044XL-09HQ240C is positioned for designers who need a commercially graded, mid-range FPGA that balances logic capacity, on-chip RAM and a high I/O count in a compact surface-mount package. Its 240-pin BFQFP exposed-pad package and standard 3.0–3.6 V supply simplify integration into conventional PCB designs.

For teams developing programmable-logic solutions that must meet RoHS requirements and operate across a standard commercial temperature window, this device delivers clear, verifiable specifications for predictable system behavior and straightforward BOM planning.

Request a quote or submit an inquiry to receive pricing, availability and lead-time information for the XC4044XL-09HQ240C.
