XC5202-6PQ100C

The XC5202-6PQ100C is a commercial-grade field programmable gate array (FPGA) from AMD, offered in a 100‑lead BQFP package. It provides a compact, low-complexity programmable logic solution with 256 logic elements and 81 user I/O pins suited for small to medium control, interfacing and glue-logic tasks.

Designed for surface-mount applications, the device operates from a single 4.75 V to 5.25 V supply and supports standard commercial temperature operation from 0 °C to 85 °C, making it appropriate for consumer and general embedded electronics designs.

Key Features

• Logic Capacity — 256 logic element cells provide the capacity for state machines, control logic and simple combinational/sequential designs.
• Logic Organization — 64 configurable logic blocks offer a structured resource set for partitioning designs into discrete functional blocks.
• I/O Count — 81 programmable I/O pins support a variety of peripheral interfaces and parallel/serial connectivity options.
• Gate Equivalent — Approximately 3,000 gates of logic density for integration of modest discrete logic and glue functions.
• Package & Mounting — 100‑lead BQFP package; supplier package listed as 100‑PQFP (20 × 14); surface-mount mounting type for PCB assembly.
• Power — Single-supply operation from 4.75 V to 5.25 V simplifies board power architecture.
• Temperature & Grade — Commercial grade with an operating range of 0 °C to 85 °C for typical consumer and office-environment use.
• Compliance — RoHS compliant.

Typical Applications

• Consumer Electronics — Implement control logic and peripheral interfacing in consumer devices where a compact, surface-mount FPGA is required.
• Prototyping & Development — Rapidly evaluate small FPGA-based designs and iterate logic implementations during product development.
• Embedded Control — Implement state machines, protocol translators and glue logic between digital subsystems using available logic elements and I/O.
• Instrumentation & Test Equipment — Provide modest programmable logic for data routing, simple timing, and control functions in benchtop instruments.

Unique Advantages

• Compact, surface-mount package: 100‑lead BQFP footprint balances board-space efficiency with sufficient I/O for many embedded tasks.
• Appropriate logic density for small systems: 256 logic elements and ~3,000 gate equivalents enable integration of common control and interfacing functions without over‑provisioning.
• Generous I/O count: 81 user I/O pins facilitate flexible connections to peripherals, sensors and external logic.
• Straightforward power requirements: Single 4.75 V–5.25 V supply simplifies power supply design in legacy 5 V systems.
• Commercial temperature rating: Operates across 0 °C to 85 °C, matching typical consumer and office-environment deployment scenarios.
• RoHS compliant: Meets standard lead-free environmental compliance expectations for modern electronics manufacturing.

Why Choose XC5202-6PQ100C?

The XC5202-6PQ100C positions itself as a practical, vendor-backed FPGA option for designers who need compact programmable logic with a clear set of resources: 256 logic elements, 81 I/Os, and a 100‑lead BQFP surface-mount package. Its single 5 V supply and commercial temperature rating make it well suited to consumer products, development boards and embedded control applications where straightforward integration and predictable operating conditions are required.

For teams building small-scale programmable-logic subsystems, the XC5202-6PQ100C delivers a balanced combination of logic capacity, I/O flexibility and a standardized package form factor from AMD, enabling easier board-level integration and supply-chain sourcing.
