LS1023AXN8MQB

The LS1023AXN8MQB is an NXP QorIQ Layerscape microprocessor featuring a dual-core ARM® Cortex®-A53 64-bit CPU running at 1.2 GHz. It is targeted at embedded networking and industrial infrastructure where efficient packet processing, rich I/O and industrial qualification are required.

Designed for small-form-factor networking and industrial applications, this device combines multi-protocol SerDes, integrated networking peripherals and security features to deliver performance, integration and operating range suitable for robust edge and industrial designs.

Key Features

• Core  Dual ARM® Cortex®-A53 64-bit processors at 1.2 GHz providing a two-core CPU complex for general-purpose compute.
• Cache and Interconnect  Includes a large L2-cache and ARM CoreLink CCI-400 coherent interconnect with SMMU for hardware-enforced memory controls (as described for the LS1023A family).
• Memory  Supports DDR3L and DDR4 memory controllers for flexible system memory choices.
• Networking and High‑Speed I/O  Multi-protocol four-lane SerDes (10 GHz) with support for multiple Ethernet configurations (up to six Gigabit Ethernet ports or a mix of 10GbE and 1GbE as specified), three PCIe 2.0 DMA-controlled ports, a single SATA 6Gbps (SATA 3.0) port, and USB 3.0 (2) with PHY.
• Data Path Acceleration  Integrates QorIQ Data Path Acceleration Architecture (DPAA) offload engines and Frame Manager functions for hardware packet parsing, classification and policing to reduce CPU overhead.
• Security  Implements Secure Boot and ARM TrustZone® along with an integrated security engine (SEC) for in-line IPsec and cryptographic offload.
• Package and Mounting  780-ball FCPBGA package (23 × 23 mm) designed for surface-mount assembly.
• Qualification and Operating Range  Industrial qualification with an operating temperature range of −40 °C to 105 °C.
• Design Targets  Purpose-built for fanless, small-form-factor networking and industrial designs with BOM optimizations for low-layer PCBs, simplified power supply and single-clock system design (as described for the LS1023A family).

Typical Applications

• Branch Office Routers: Compact routing platforms requiring multi-port Ethernet, hardware packet processing and secure transport.
• vCPE and Edge Appliances: Virtualized customer premises equipment and edge devices that benefit from dual-core 64-bit processing and DPAA offloads.
• IoT and Multi‑Protocol Gateways: Gateways handling protocol conversion and packet classification for IoT deployments.
• Industrial PLC and Control: Industrial control systems needing industrial temperature operation and robust I/O integration.
• Security Appliances: Network security devices leveraging integrated SEC and Frame Manager capabilities for inline IPsec and packet processing.

Unique Advantages

• Balanced dual‑core 64‑bit performance: ARM Cortex‑A53 cores at 1.2 GHz deliver general-purpose compute for control-plane and edge workloads.
• Integrated high‑speed I/O: Multi-protocol SerDes, PCIe, SATA and USB 3.0 reduce the need for external controllers and simplify system BOM.
• Packet offload and frame management: DPAA and Frame Manager capabilities provide hardware packet parsing and classification to lower CPU overhead.
• Built‑in security primitives: Secure Boot, TrustZone® and an integrated security engine enable secure device boot and inline cryptographic processing.
• Industrial operating range: −40 °C to 105 °C qualification supports deployment in harsh environments.
• Compact BGA package: 780-FCPBGA (23×23 mm) surface-mount package enables small-form-factor board designs.

Why Choose LS1023AXN8MQB?

The LS1023AXN8MQB positions itself as a compact, industrially qualified Layerscape solution that blends dual-core 64-bit processing with extensive networking and security integration. Its combination of multi-protocol SerDes, DPAA offloads and secure boot capabilities makes it well suited for edge networking, industrial control and security-focused embedded systems.

Designers seeking a small-form-factor processor with flexible memory support, rich I/O and an industrial temperature rating will find the LS1023AXN8MQB delivers the integration needed to simplify BOM and system design while addressing the throughput and security requirements of modern embedded networking applications.

Request a quote or submit a product inquiry to receive pricing, lead-time and availability information for LS1023AXN8MQB.
