MC8640DTHX1000HE

The MC8640DTHX1000HE is a dual-core PowerPC e600 microprocessor in the MC8640 series from NXP Semiconductors. It delivers 1.0 GHz performance in a 1023‑FCCBGA (33×33) surface‑mount package tailored for embedded system designs.

Designed for embedded applications requiring integrated memory interfaces and multi‑port Ethernet connectivity, this device combines dual 32‑bit cores with DDR/DDR2 memory controller support and four 10/100/1000 Mbps Ethernet ports to address networking and compute‑centric embedded designs.

Key Features

• Processor Core PowerPC e600 architecture with 2 cores at 1 GHz, delivering deterministic 32‑bit processing for embedded control and data‑plane tasks.
• Memory Interfaces Integrated controllers for DDR and DDR2 memory types to support system memory configurations for embedded applications.
• High‑Speed Ethernet Four 10/100/1000 Mbps Ethernet ports enable multi‑port networking and high‑bandwidth connectivity options on a single IC.
• Package and Mounting 1023‑FCCBGA (33×33) supplier device package in tray format, designed for surface‑mount assembly in compact embedded form factors.
• Debug and Test Series documentation for MC8640 variants references modified JTAG AC timing (example: tJTDVKH min = 15 ns) to support boundary‑scan and device debug workflows.
• Series Documentation The MC8640 series datasheet addendum provides recommended operating conditions and electrical specification details for MC8640 family variants.

Typical Applications

• Network and Communications Equipment Four 10/100/1000 Mbps Ethernet ports and dual PowerPC cores make the device suitable for embedded routers, switches, and network appliances that require integrated multi‑port connectivity.
• High‑Performance Embedded Control Dual 1 GHz PowerPC cores and DDR/DDR2 memory support enable real‑time control and compute tasks in industrial controllers and automation platforms.
• Embedded Infrastructure Compact BGA packaging and surface‑mount assembly fit system designs where board space and integration of multiple functions are priorities.

Unique Advantages

• Dual‑Core Processing Two 32‑bit cores at 1 GHz allow partitioning of networking and application workloads on a single device, reducing system complexity.
• Integrated Memory Support Built‑in DDR and DDR2 controllers simplify BOM and board design by providing standard high‑speed memory interfaces.
• Multi‑Port Ethernet Four gigabit Ethernet interfaces provide native connectivity for multi‑port embedded networking without external PHY aggregation.
• Compact BGA Package 1023‑FCCBGA (33×33) package enables dense board layouts and supports surface‑mount manufacturing processes.
• Series‑Level Documentation MC8640 series documentation includes recommended operating conditions and electrical specifications to support system integration and qualification activities.

Why Choose MC8640DTHX1000HE?

The MC8640DTHX1000HE combines dual PowerPC e600 cores, integrated DDR/DDR2 memory controllers, and four gigabit Ethernet ports in a compact 1023‑FCCBGA package—making it a strong option for embedded systems that require a balance of compute and multi‑port network capability. As part of the NXP MC8640 series, it benefits from series documentation that details operating conditions and device timing for system design.

This device is suited to designers of embedded networking equipment, industrial control platforms, and other integrated systems where on‑chip memory interfaces and multi‑port Ethernet connectivity reduce board-level component count and simplify system architecture.

Request a quote or submit an inquiry to receive pricing and availability information for the MC8640DTHX1000HE and supporting documentation.
