MPC880VR66

The MPC880VR66 is a single‑core 32‑bit microprocessor in the MPC8xx/PowerQUICC family from NXP Semiconductors, running at 66 MHz. It combines a MPC8xx core with integrated system peripherals and a communications processor module (CPM), targeting embedded controller, communications and networking applications.

Key Features

• Core and Architecture  MPC8xx single‑issue 32‑bit core at 66 MHz with the Power Architecture™ design principles as specified for the MPC885/MPC880 family.
• Memory and MMU  Integrated memory management units (MMUs) with instruction and data caches to support efficient code and data handling; family datasheet references 8 KB instruction and 8 KB data caches.
• Communications Processor (CPM)  On‑chip CPM and communications co‑processor resources for HDLC/SDLC and other serial protocols, enabling offload of packet and link layer tasks.
• Ethernet and USB  Multiport Ethernet capability (two 10 Mbps ports and two 10/100 Mbps ports) plus one USB 2.0 interface for a variety of wired network and peripheral connectivity options.
• DRAM Controller  Integrated DRAM controller simplifies external memory interfacing for system designs requiring external working memory.
• I/O Voltage  3.3 V I/O support for compatibility with common embedded logic levels.
• Package and Mounting  357‑ball PBGA (25 × 25 mm) surface‑mount package for compact board footprint and high pin density.
• Operating Range and Compliance  Consumer qualification with an operating temperature range of 0 °C to 95 °C and RoHS compliance.

Typical Applications

• Embedded Networking Devices  Multiport Ethernet and USB interfaces make the MPC880VR66 suitable for routers, switches, and appliance gateways where integrated communications are required.
• Communications Controllers  CPM and HDLC/SDLC support enable protocol offload and line‑level processing for telecom and data link controller designs.
• Industrial Embedded Controllers  Integrated DRAM controller and robust operating temperature range support control systems and industrial interfaces.
• Consumer Networking Equipment  The combination of Ethernet, USB 2.0, and a compact PBGA package fits consumer router, modem, and home network appliance designs.

Unique Advantages

• Integrated Communications Subsystem  On‑chip CPM plus multiple Ethernet ports and USB reduce external components and simplify board design for networked systems.
• Single‑Chip Solution  Core, MMU, caches, DRAM controller and peripheral interfaces on one device lower BOM count and streamline integration.
• Industry‑Proven Family  As part of the MPC885/MPC880 PowerQUICC family, design teams can rely on consistent architectural features across family variants.
• Compact High‑Density Package  357‑ball PBGA (25×25) enables a space‑efficient implementation on surface‑mount PCBs.
• Standard 3.3 V I/O and RoHS Compliance  Simplifies interfacing with common logic levels and meets environmental compliance expectations.
• Wide Consumer Temperature Range  Rated 0 °C to 95 °C to support a broad set of commercial and industrial indoor deployments.

Why Choose MPC880VR66?

The MPC880VR66 delivers a balanced combination of embedded processing and integrated communications peripherals in a single 32‑bit MPC8xx core device. Its multiport Ethernet, USB 2.0 interface, CPM offload capability and onboard DRAM controller make it well suited to embedded networking, communications controllers and consumer networking equipment where integration and board‑level simplicity matter.

Designed within the MPC8xx/PowerQUICC family framework and provided by NXP Semiconductors, the MPC880VR66 is targeted at engineers seeking a compact, RoHS‑compliant processor module with established family features and a focus on communications and embedded control tasks.

Request a quote or submit a parts inquiry today to receive pricing and availability information for the MPC880VR66.
