MPC885VR66
| Part Description |
MPC8xx Microprocessor IC MPC8xx 1 Core, 32-Bit 66MHz 357-PBGA (25x25) |
|---|---|
| Quantity | 1,445 Available (as of October 8, 2026) |
| Product Category | Microprocessors |
|---|---|
| Part Series | MPC885 |
| Manufacturer | NXP USA Inc. |
| Manufacturing Status | Obsolete |
| Manufacturer Standard Lead Time | Contact Us |
| Datasheet |
Specifications & Environmental
| Co-Processors/DSP | Communications; CPM, Security; SEC | Core Processor | MPC8xx | Device Package | 357-PBGA (25x25) | ||
|---|---|---|---|---|---|---|---|
| ECCN | 5A002A1 FRE | Ethernet | 10Mbps (3), 10/100Mbps (2) | Graphics Acceleration | No | ||
| HTS Code | 8542.31.0001 | Moisture Sensitivity Level | 3 (168 Hours) | Mounting Method | Surface Mount | ||
| Mounting Type | Surface Mount | Number of Cores/Bus Width | 1 Core, 32-Bit | Operating Temperature | 0°C ~ 95°C (TA) | ||
| Package / Case | 357-BBGA | RAM Controllers | DRAM | REACH Compliance | REACH Unaffected | ||
| RoHS Compliance | ROHS3 Compliant | Security Features | Cryptography | Speed | 66MHz | ||
| Supplier Device Package | 357-PBGA (25×25) | USB | USB 2.0 (1) | Voltage – I/O | 3.3V |
Overview of MPC885VR66 – IC MPU MPC8XX 66MHz 357-PBGA
The MPC885VR66 is a single-core, 32-bit microprocessor based on the MPC8xx Power Architecture core, optimized for embedded controller and communications applications. It integrates a CPU core, system integration functions and the Communications Processor Module (CPM), delivering a compact, highly integrated solution for networking, communications and embedded control designs.
With a 66 MHz core, 3.3 V I/O, on-chip cryptography support and a 357-PBGA (25×25) surface-mount package, the MPC885VR66 targets designs requiring integrated peripheral support, deterministic interfaces and industry-standard connectivity options.
Key Features
- Core and Architecture – MPC8xx single 32-bit core built on Power Architecture technology with instruction and data caches (8 KB each), providing deterministic processing for embedded tasks.
- Clock Speed – 66 MHz core frequency, suitable for control and communications workloads where predictable timing is required.
- Voltage and Mounting – 3.3 V I/O and surface-mount 357-PBGA (25×25) package for compact board-level integration.
- Communications Co-processors – Integrated Communications Processor Module (CPM) and security co-processor (SEC) for offloading protocol and cryptography functions.
- Ethernet – Multiple Ethernet controllers: three 10 Mbps controllers and two 10/100 Mbps controllers for flexible network interfacing.
- USB – Single USB 2.0 interface for host or device connectivity.
- Memory Support – DRAM controller on-chip to support external memory for system code and data.
- Additional Interfaces – HDLC/SDLC support for serial framing and legacy communications protocols.
- Security Features – On-chip cryptography block to support secure communications and data protection tasks.
- Operating Range – Specified operating temperature range of 0 °C to 95 °C for consumer-grade deployments.
- Compliance – RoHS compliant for modern manufacturing and environmental standards.
Typical Applications
- Embedded Controllers – Use as the main processing element in controllers requiring integrated peripheral support and deterministic I/O timing.
- Networking and Communications Equipment – Leverage multiple Ethernet controllers, the CPM and HDLC/SDLC interfaces for routers, switches and protocol gateways.
- Security and Encryption Appliances – On-chip cryptography and the SEC co-processor enable secure data handling and encrypted communications.
- USB-Enabled Devices – Integrate USB 2.0 connectivity for device or host roles in consumer and industrial peripherals.
Unique Advantages
- Highly integrated communications peripherals – Multiple Ethernet controllers, CPM and HDLC/SDLC support reduce external interface components and simplify board design.
- On-chip security acceleration – Built-in cryptography and SEC co-processor offload security operations from the CPU core, improving throughput for encrypted traffic.
- Compact BGA package – 357-PBGA (25×25) package enables dense PCB layouts while supporting high-pin-count connectivity.
- Deterministic 32-bit core – Single MPC8xx core with dedicated caches provides stable, predictable performance for embedded control tasks.
- Broad interface set – Ethernet, USB 2.0, DRAM controller and serial framing interfaces allow the MPC885VR66 to serve multiple roles within a system.
- RoHS compliant – Supports environmentally conscious manufacturing requirements.
Why Choose MPC885VR66?
The MPC885VR66 combines a Power Architecture-based MPC8xx core with a Communications Processor Module and dedicated security resources to deliver a single-chip solution for embedded communications and control applications. Its mix of Ethernet ports, USB 2.0, DRAM support and HDLC/SDLC interfaces makes it suitable for designs that need integrated connectivity and protocol handling in a compact footprint.
Designed for consumer-grade temperature environments and supplied in a 357-PBGA (25×25) package, the MPC885VR66 offers a balance of integration, interface breadth and deterministic processing for developers building networking equipment, secure communication appliances and embedded controllers within the MPC885 family ecosystem.
Request a quote or submit a purchase inquiry for the MPC885VR66 to obtain pricing, availability and ordering information.
