N80186-10

The N80186-10 is an 80186 microprocessor IC from Advanced Micro Devices, part of the Am80186 series. It provides a single 16-bit core running at 10 MHz with integrated system interfaces tailored for embedded applications.

Designed for embedded systems, the device includes integrated DRAM control and DMA support, 5 V I/O compatibility, and a commercial operating range, packaged in a surface-mount 68-PLCC footprint for compact board-level integration.

Key Features

• Core Single 80186 core with a 16-bit architecture suitable for embedded control tasks.
• Performance 10 MHz clock rate providing deterministic processing for legacy and resource-constrained designs.
• Memory & DMA Integrated DRAM controllers and DMA interface support to simplify memory interfacing and data transfers.
• I/O Voltage 5 V I/O compatibility for direct interfacing with legacy 5 V peripherals.
• Package & Mounting 68-PLCC supplier device package (24.21×24.21) in a 68-LCC (J-Lead) surface-mount case for compact PCB layouts.
• Operating Range Commercial grade operation from 0°C to 70°C.
• Interfaces Additional DMA interface available for efficient peripheral-to-memory transfers.
• Environmental RoHS compliant.

Typical Applications

• Embedded Control Systems — Use as the primary MCU for control and sequencing tasks in embedded equipment requiring a 16-bit processor.
• Industrial Equipment — Suitable for commercial-grade industrial controllers and instrumentation operating within 0°C to 70°C.
• Legacy System Designs — Ideal for maintaining or upgrading systems that rely on 80186 architecture and 5 V I/O compatibility.
• Memory-Managed Applications — Designs that require on-chip DRAM control and DMA-based data movement benefit from integrated interfaces.

Unique Advantages

• Integrated Memory Interfaces: On-chip DRAM controller reduces external component count and simplifies memory subsystem design.
• DMA Support: Built-in DMA enables efficient data transfers without continuous CPU intervention.
• Classic 16‑Bit Architecture: Single 80186 core provides a known architecture for legacy-compatible embedded designs.
• Compact Surface-Mount Package: 68-PLCC (24.21×24.21) in a 68-LCC J-lead package supports dense PCB layouts and surface-mount assembly.
• Commercial Temperature Rating: 0°C to 70°C operation targets a wide range of standard embedded and industrial environments.
• Manufacturer Backing: Produced by Advanced Micro Devices as part of the Am80186 series.

Why Choose N80186-10?

The N80186-10 positions itself as a compact, integration-focused microprocessor suitable for embedded designs that require a 16-bit 80186 core, on-chip DRAM control, and DMA capabilities. Its 5 V I/O and commercial temperature range make it a practical choice for systems that maintain legacy interfaces while benefiting from integrated memory handling.

Engineers and procurement teams looking for a vendor-backed Am80186 series device will find the N80186-10 a straightforward option for consolidating system functions into a single surface-mount package and simplifying board-level design.

Request a quote or submit an inquiry to receive pricing and availability information for the N80186-10.
