EPF10K100BQC208-2

The EPF10K100BQC208-2 is a FLEX-10K® field programmable gate array (FPGA) from Altera designed for commercial applications requiring moderate logic density and on-chip memory. This device integrates 576 logic elements, 6,144 bits of embedded RAM and up to 147 I/O pins in a 208-pin BFQFP package, operating from a 4.75 V to 5.25 V supply and rated for 0 °C to 70 °C.

Key Features

• Logic Resources  576 logic elements provide a compact FPGA fabric suitable for glue logic, control functions, and small to moderate digital designs.
• Embedded Memory  6,144 bits of on-chip RAM for small data buffers, state storage, and lookup tables.
• I/O Capacity  Up to 147 I/O pins accommodate multiple parallel interfaces, peripheral connections, and board-level signal routing.
• Package  208-BFQFP (208-PQFP, 28×28) surface-mount package for PCB-mounted designs where a compact, high-pin-count footprint is required.
• Power  Single 4.75 V to 5.25 V supply simplifies power rail requirements in 5 V systems.
• Operating Range  Commercial grade operation from 0 °C to 70 °C, appropriate for typical consumer and general-purpose electronics environments.
• Compliance  RoHS compliant, supporting lead-free manufacturing processes.

Typical Applications

• Consumer Electronics  Implement control logic, peripheral interface glue, and small-scale signal processing where a commercial-grade FPGA and 5 V compatibility are needed.
• Embedded Controllers  Integrate finite-state machines, bus interfacing, and custom logic functions using the 576 logic elements and available on-chip RAM.
• Prototyping and Development  Suitable for board-level prototyping and evaluation in designs that require moderate logic density and a 208-pin package footprint.
• Interface Bridging  Use the device’s 147 I/O pins to translate, buffer, or aggregate multiple low- to medium-pin-count peripherals on a single FPGA.

Unique Advantages

• Compact Logic Integration: 576 logic elements enable consolidation of discrete logic and small-state systems onto one device, reducing BOM and PCB area.
• Ample I/O Count: 147 I/O pins provide flexibility for parallel interfaces and multiple peripheral connections without external expander chips.
• Standard 5 V Support: Direct operation from a 4.75 V to 5.25 V supply streamlines integration into existing 5 V platforms.
• Surface-Mount 208-Pin Package: The 208-BFQFP package offers a high pin count in a board-friendly form factor for compact system designs.
• RoHS Compliant: Meets lead-free manufacturing requirements for modern assembly processes.

Why Choose EPF10K100BQC208-2?

The EPF10K100BQC208-2 is positioned for designers seeking a commercially graded FPGA with moderate logic capacity, on-chip RAM, and a high number of I/O in a 208-pin surface-mount package. Its 5 V supply compatibility and RoHS compliance make it well suited to consumer and general-purpose electronics where those constraints apply.

This Altera FLEX-10K device is a practical choice for engineers consolidating control logic, implementing interface functions, or developing prototypes that require a balance of logic resources, I/O flexibility, and a compact package footprint.

Request a quote or submit an inquiry to receive pricing and availability information for the EPF10K100BQC208-2.
