XC3130-PQ100IPH

The XC3130-PQ100IPH is a Field Programmable Gate Array (FPGA) offered by AMD designed for embedded logic and control functions. It provides 100 logic elements with 22,176 bits of on-chip RAM and up to 80 general-purpose I/O pins, making it suitable for compact, industrial-grade designs.

With a single-supply operating range of 4.5 V to 5.5 V and an industrial operating temperature range of −40 °C to 100 °C, this surface-mount device is aimed at applications that require moderate logic density, on-chip memory, and robust environmental tolerance.

Key Features

• Core Logic 100 logic elements for implementing custom combinatorial and sequential logic functions.
• Embedded Memory 22,176 bits of on-chip RAM (approximately 0.022 Mbits) to store state, buffers or small lookup tables.
• I/O 80 general-purpose I/O pins supporting a variety of external interfaces and glue-logic roles.
• Power Single-supply operation from 4.5 V to 5.5 V for straightforward integration with standard 5 V systems.
• Package and Mounting 100-BQFP package case; supplier device package listed as 100-PQFP (20×14). Surface-mount mounting type for PCB assembly.
• Industrial Temperature Range Rated for −40 °C to 100 °C to support deployment in harsh and variable environments.
• RoHS Compliant Meets RoHS requirements for lead-free assembly and environmental compliance.

Typical Applications

• Industrial Control Implement control sequencing, simple state machines, and I/O aggregation in industrial systems using the industrial temperature rating and 80 I/O pins.
• Sensor and Actuator Interfacing Handle sensor signal conditioning, gating, and timing with on-chip logic and embedded RAM for buffering.
• Glue Logic and Peripheral Expansion Replace discrete logic for board-level glue functions and expand microcontroller connectivity with programmable I/O.

Unique Advantages

• Compact Logic Density: 100 logic elements provide a compact programmable fabric for modest logic integration without excessive footprint.
• Integrated On-Chip RAM: 22,176 bits of embedded memory reduce external memory requirements for small buffers and state storage.
• High I/O Count for the Package: 80 I/O pins in a 100-pin package enable multiple peripheral connections from a single device.
• Industrial Reliability: Rated for −40 °C to 100 °C operation to suit temperature-demanding installations.
• Standard 5 V Supply: Operates from 4.5 V to 5.5 V for compatibility with common legacy and industrial power rails.
• RoHS Compliance: Designed for lead-free manufacturing and regulatory compliance in modern assemblies.

Why Choose XC3130-PQ100IPH?

The XC3130-PQ100IPH positions itself as a practical FPGA choice for designs that require modest logic density, meaningful on-chip RAM, and a substantial number of I/O lines in a 100-pin surface-mount package. Its industrial temperature rating and 5 V supply compatibility make it suitable for embedded and industrial applications where environmental tolerance and straightforward integration are important.

Choose this device when you need a compact, programmable solution to consolidate glue logic, handle sensor/actuator interfaces, or add flexible I/O expansion while keeping board-level complexity and external memory requirements low.

Request a quote or submit an inquiry to obtain pricing, availability, and ordering information for the XC3130-PQ100IPH.
