XC4013XL-09BG256C

The XC4013XL-09BG256C is a programmable logic device from the XC4000E/X family intended for commercial embedded logic designs. It provides a mid-range balance of configurable logic, on-chip RAM, and I/O resources for applications that require flexible digital implementation in a surface-mount BGA package.

Key Features

• Core Logic  576 CLBs and 1,368 logic elements (cells) delivering approximately 13,000 gates of programmable logic for implementing custom digital functions.
• Embedded Memory  18,432 bits of on-chip RAM for local buffering, state storage, and small data structures without external memory.
• I/O Capacity  192 user I/O pins to support multiple interfaces, peripheral connections, and board-level signal routing.
• Package & Mounting  256-BBGA package; supplier device package listed as 256-PBGA (27×27). Surface-mount mounting type suitable for compact PCB layouts.
• Power  Operates from a 3.0 V to 3.6 V supply range, compatible with common 3.3 V system rails.
• Operating Range & Grade  Commercial-grade device with an operating temperature range of 0 °C to 85 °C.
• Regulatory Compliance  RoHS compliant.

Typical Applications

• Embedded Control  Implement custom control logic and state machines using the available CLBs and logic elements to offload tasks from microcontrollers.
• Interface Bridging  Use the 192 I/O pins for protocol conversion, signal translation, and glue-logic between digital subsystems.
• Prototyping and Development  Evaluate and iterate digital designs that require moderate amounts of programmable logic and on-chip RAM.

Unique Advantages

• Balanced logic density: 576 CLBs and 1,368 logic elements provide a practical resource set for mid-complexity designs without excessive device cost.
• Integrated on-chip RAM: 18,432 bits of embedded memory reduce dependence on external memories for small buffers and state storage.
• High I/O count in a compact package: 192 I/Os in a 256-BBGA footprint enable dense connectivity for peripherals and board-level interfaces.
• Standard commercial qualification: Rated for 0 °C to 85 °C operation, suitable for a wide range of commercial products and environments.
• RoHS compliant: Conforms to lead-free and hazardous substance regulations required in many procurement programs.

Why Choose XC4013XL-09BG256C?

The XC4013XL-09BG256C offers a compact, mid-range FPGA solution providing a blend of programmable logic, embedded RAM, and abundant I/O in a 256-BBGA surface-mount package. Its 3.0–3.6 V supply range and commercial temperature rating make it suitable for standard commercial embedded systems that require configurable digital functionality.

Manufactured by AMD and drawn from the XC4000E/X family, this device is appropriate for designers seeking a commercially graded FPGA option with clearly specified logic, memory, and I/O resources for prototyping, interface control, and embedded logic tasks.

Request a quote or submit an inquiry to obtain pricing, lead-time, and availability for the XC4013XL-09BG256C.
