XC4013XL-09HT144C

The XC4013XL-09HT144C is a field programmable gate array (FPGA) device from AMD's XC4000E/X family, provided in a 144-lead LQFP package with an exposed pad. It delivers a balanced combination of logic density, embedded RAM and I/O resources for commercial-grade digital designs.

With 1,368 logic elements, 18,432 bits of on-chip RAM and 113 I/O pins, this FPGA is suitable for a range of commercial applications that require moderate programmable logic capacity and a 3.0–3.6 V supply operating range.

Key Features

• Core Logic  Approximately 1,368 logic elements and an estimated 13,000 gates provide programmable digital resources for implementing custom logic and state machines.
• Embedded Memory  18,432 bits of on-chip RAM (approximately 0.018 Mbits) for data buffering, small lookup tables or state storage.
• I/O  113 user I/O pins to interface with peripherals, buses and external devices in board-level systems.
• Power  Operates from a 3.0–3.6 V supply, matching common commercial logic power domains.
• Package and Mounting  144-LQFP exposed pad package (supplier device package listed as 144-TQFP, 20×20) in a surface-mount form factor for PCB assembly.
• Operating Range  Commercial-grade operating temperature range of 0 °C to 85 °C for standard commercial deployments.
• Compliance  RoHS compliant, meeting common environmental requirements for electronic assemblies.

Typical Applications

• Commercial Embedded Systems  Implement custom digital functions and control logic within commercial electronic products that operate within 0 °C to 85 C.
• Interface Bridging  Use the FPGA's 113 I/O pins to glue different bus standards or peripherals together on a single PCB.
• Prototyping and Development  Prototype moderate-complexity digital designs that require reprogrammable logic and modest on-chip RAM.
• User Interface Control  Drive and coordinate multiple I/O signals for displays, keypads, or simple human-machine interfaces in commercial equipment.

Unique Advantages

• Balanced Logic Capacity: 1,368 logic elements provide a mid-range programmable resource suitable for many commercial digital designs without over-provisioning.
• On-Chip Memory: 18,432 bits of embedded RAM give local data storage for buffering, small FIFOs or table lookup functions.
• Generous I/O Count: 113 I/O pins enable flexible interfacing to peripherals, sensors and external controllers on compact boards.
• Standard Commercial Range: Specified for 0 °C to 85 C operation and 3.0–3.6 V supply, fitting common commercial product requirements.
• Surface-Mount Packaging: 144-pin LQFP with exposed pad and supplier-listed 144-TQFP (20×20) option supports standard PCB manufacturing and assembly workflows.
• Regulatory Alignment: RoHS compliance supports environmentally conscious product builds and assembly processes.

Why Choose XC4013XL-09HT144C?

The XC4013XL-09HT144C positions itself as a commercially graded, mid-density FPGA that combines moderate logic resources, on-chip RAM and ample I/O in a compact 144-lead surface-mount package. It is a practical choice for designers who need reprogrammable logic for commercial applications running at standard ambient temperatures and common supply voltages.

Backed by AMD as the manufacturer, this device suits development and production scenarios where predictable supply voltage, defined operating temperature range and RoHS compliance are required. It provides a clear capacity point for teams balancing resource needs, board area and assembly considerations.

Request a quote or submit an inquiry to receive pricing and availability for the XC4013XL-09HT144C for your next commercial FPGA design.
