AM6422BSDGHAALV

The AM6422BSDGHAALV is a Sitara™ microprocessor IC from Texas Instruments featuring a heterogeneous 5-core, 64‑bit architecture with ARM® Cortex®‑A53, ARM® Cortex®‑M5F and ARM® Cortex®‑R5F processor cores. It delivers multi-domain processing capability with core frequencies up to 1 GHz, 800 MHz and 400 MHz for application, real‑time and microcontroller tasks, respectively.

Designed for industrial embedded systems, this device integrates high‑performance processing, memory controllers for DDR4/LPDDR4, multiple Ethernet ports, USB 3.1 connectivity, CANbus and extensive security features—providing a compact, industrial‑grade building block for communication‑centric and real‑time control applications.

Key Features

• Heterogeneous Multi‑Core Architecture 5‑core, 64‑bit processor composition including ARM® Cortex®‑A53, Cortex®‑R5F and Cortex®‑M5F cores with operating points up to 1 GHz, 800 MHz and 400 MHz respectively for scalable application, real‑time and MCU workloads.
• Industrial Communication Subsystems Integrated industrial communication support with multiple Ethernet interfaces and PRU_ICSSG capabilities for Profinet IRT/RT, EtherNet/IP, EtherCAT and Time‑Sensitive Networking (TSN) as described in the device series documentation.
• Memory and Storage On‑chip memory architecture supports up to 2 MB of OCSRAM with SECDED ECC and a DDR subsystem compatible with DDR4 and LPDDR4 memory types, including inline ECC and support up to 1600 MT/s (series specification).
• High‑Speed Interfaces Multiport Ethernet: two 10/100 Mbps and two 10/100/1000 Mbps interfaces, plus one USB 3.1 port and CANbus support for flexible system connectivity.
• Security and Trusted Boot Hardware security features include AES, 3DES, DES, MD5, SHA‑1/2, secure boot, cryptography accelerators and support for a Trusted Execution Environment and secure storage (as outlined in series documentation).
• Industrial Reliability and Packaging Industrial grade device with operating temperature range of −40 °C to 105 °C, supplied in a 441‑FCBGA (17.2 × 17.2 mm) surface‑mount package suitable for compact embedded designs.
• SoC Services and DMA On‑chip system services including device management controller, block copy and packet DMA, secure proxy and ring accelerator capabilities to streamline data movement and system control (series level features).
• Standards‑level Compliance RoHS compliant material status for regulatory and manufacturing compatibility.

Typical Applications

• Industrial Automation and Motion Control — Use the integrated industrial communication subsystems and real‑time R5F cores for deterministic motor control, encoder interfaces and machine‑control tasks.
• Industrial Ethernet Gateways and Protocol Translators — Multiport Gigabit and 10/100 Ethernet combined with PRU_ICSSG support enables protocol conversion, TSN and fieldbus bridging.
• Robotics and Autonomous Systems — Heterogeneous cores allow separation of high‑level application processing, real‑time control and safety‑critical MCU functions within a single device.
• Secure Embedded Controllers — Hardware cryptography, secure boot and TEE support help implement protected firmware and secure device lifecycle management.

Unique Advantages

• Highly Integrated Heterogeneous Processing: Consolidates application, real‑time and MCU domains on one chip to reduce BOM and simplify system architecture.
• Deterministic Industrial I/O: PRU_ICSSG‑based industrial subsystems and multiport Ethernet support deterministic communications and fieldbus protocols for factory and process automation.
• Memory Flexibility with ECC: DDR4/LPDDR4 support and on‑chip OCSRAM with SECDED ECC enable robust data integrity and a range of memory configurations.
• Comprehensive Security Building Blocks: On‑chip cryptography, secure boot and TEE support streamline implementation of secure devices and help protect firmware and data.
• Industrial‑Grade Temperature Range: −40 °C to 105 °C rating supports deployment in harsh and temperature‑varied industrial environments.
• Compact, Surface‑Mount Package: 441‑FCBGA (17.2 × 17.2 mm) package allows high integration in space‑constrained embedded designs.

Why Choose AM6422BSDGHAALV?

The AM6422BSDGHAALV positions itself as an integrated solution for embedded industrial systems requiring mixed application and real‑time processing, robust communications and built‑in security. Its heterogeneous ARM core mix, memory subsystem with ECC, and industrial communication features make it well suited for gateway, control and automation designs that need consolidated functionality in a compact package.

This device is aimed at designers who require deterministic I/O, flexible memory options and built‑in security primitives while operating across an industrial temperature range. The combination of multiport Ethernet, USB 3.1, CANbus and SoC-level services supports scalable system architectures and lifecycle robustness for long‑running industrial deployments.

Request a quote or submit a procurement inquiry for AM6422BSDGHAALV to obtain pricing and availability information for your design and production planning.
