MC9328MX1CVM15R2

The MC9328MX1CVM15R2 is a single-core ARM920T 32-bit microprocessor operating at 150 MHz, designed for embedded and portable applications. It integrates a range of on-chip system functions—memory controllers, display and human-interface controllers, serial interfaces and USB device support—targeting designs that require compact, industrially qualified processing with peripheral integration.

Manufactured by NXP Semiconductors and offered in a 256-contact MAPBGA surface-mount package, the device is RoHS compliant and specified for industrial temperature operation from −40 °C to 85 °C.

Key Features

• Core ARM920T single-core, 32-bit processor running at 150 MHz for deterministic embedded processing.
• Memory and DMA Integrated SDRAM controller and on-chip DMA controller plus embedded SRAM (series documentation references 128 KB eSRAM) to support system memory and high-throughput transfers.
• Display and Human Interface On-chip LCD controller and touch-panel support for direct connection to display subsystems and human-interface circuitry.
• Connectivity and Peripherals USB device support, MMC/SD and Memory Stick® host controller modules, multiple UARTs and SPI interfaces, I2C and synchronous serial (SSI/I2S) modules provide broad peripheral connectivity.
• Timers, RTC and Control Multiple general-purpose 32-bit timers, PWM module, watchdog timer and real-time clock for system control and timing functions.
• Audio and Multimedia Support SSI/I2S interfaces and multimedia-oriented controllers (video port, ASP) as documented for the i.MX1 series.
• System Integration AHB-to-IP bus interfaces, External Interface Module (EIM), direct memory access controller (DMAC), and bootstrap facilities streamline board-level integration and boot configuration.
• Package and Mounting 256-contact MAPBGA (surface-mount) packaging for compact board layouts and high-density designs.
• Industrial Qualification and Temperature Industrial qualification with operating temperature range from −40 °C to 85 °C for deployment in demanding environments.
• Compliance RoHS compliant per product data.
• Graphics Acceleration No dedicated graphics acceleration is present.

Typical Applications

• Portable Multimedia Devices — Integration of LCD controller, audio interfaces and MMC/SD host enables compact handheld multimedia and consumer portable products.
• Human-Machine Interfaces (HMI) — LCD and touch-panel support combined with GPIO and serial interfaces suit industrial HMIs and control panels operating across the industrial temperature range.
• Embedded Connectivity Devices — Multiple UARTs, SPI, I2C and USB device support provide connectivity for peripherals, modules and sensor interfaces in embedded systems.

Unique Advantages

• Integrated Peripheral Set: On-chip display controller, USB device, MMC/SD and serial interfaces reduce external component count and simplify BOM.
• Industrial Temperature Rating: Specified operation from −40 °C to 85 °C supports deployment in harsh or outdoor environments.
• Compact MAPBGA Package: 256-contact MAPBGA enables a small board footprint while retaining extensive I/O and memory interfaces.
• Deterministic 32-bit Processing: ARM920T core at 150 MHz provides a predictable execution environment for embedded control and user-interface tasks.
• Documented Series Features: Core and subsystem capabilities are supported by NXP/Freescale technical documentation for design and validation.

Why Choose MC9328MX1CVM15R2?

The MC9328MX1CVM15R2 combines a 150 MHz ARM920T core with a wide range of integrated peripherals and memory interfaces to deliver a compact, industrially qualified solution for embedded and portable designs. Its on-chip controllers—display, storage host, serial interfaces and DMA—help reduce external components and simplify system design.

This part is suited for engineers building industrial HMIs, portable multimedia products and embedded connectivity devices that require a balance of integration, predictable 32-bit processing and a MAPBGA footprint. Technical documentation from NXP supports design, integration and validation activities for projects targeting industrial operating conditions.

If you would like pricing, availability or a formal quote for the MC9328MX1CVM15R2, submit a request or contact sales to start the procurement process.
