N80C286-16TR

The N80C286-16TR is an 80C286 microprocessor IC from Advanced Micro Devices, featuring a single 16-bit core running at 16 MHz in a 68-pin PLCC surface-mount package. Designed for embedded and industrial applications, this device combines the Am80286 series core architecture with industrial-grade operating parameters for systems that require a robust, legacy-compatible MPU.

With a single 5 V I/O supply, support for an external 80C287 math co‑processor, and an operating temperature range from −40 °C to 85 °C, the N80C286-16TR is specified for environments that demand durable performance and predictable electrical characteristics.

Key Features

• Core  80C286 single-core, 16-bit microprocessor architecture implemented in the Am80286 series.
• Performance  16 MHz clock rate suitable for control and embedded processing tasks.
• Power  5 V I/O supply voltage for compatibility with legacy 5 V system logic.
• Co‑Processor Support  External math engine support specified for the 80C287 co-processor to offload numeric workloads.
• Package & Mounting  68‑lead PLCC (68-LCC J‑lead) surface-mount package with supplier device package dimension 24.21×24.21 mm, enabling compact board-level integration.
• Industrial Grade & Temperature Range  Industrial grade device rated for operation from −40 °C to 85 °C for extended temperature environments.
• Compliance  RoHS compliant to meet environmental directive requirements.

Typical Applications

• Embedded Systems  Integration as the main processing element in compact embedded controllers and general-purpose embedded boards.
• Industrial Control Equipment  Use in industrial-grade control and monitoring systems that require an extended operating temperature range.
• Legacy System Support  Replacement or refurbishment of boards that require an Am80286-series 16-bit processor in a PLCC footprint.

Unique Advantages

• Industrial temperature rating: Operation from −40 °C to 85 °C supports deployment in demanding thermal environments.
• Single 5 V I/O supply: Simplifies power rail requirements for systems designed around 5 V logic.
• Co‑processor capability: Support for the 80C287 math engine enables hardware acceleration of math-intensive tasks when required.
• Surface-mount PLCC package: 68‑lead PLCC (24.21×24.21 mm) offers a compact, board-level form factor for space-constrained designs.
• RoHS compliant: Meets environmental compliance requirements for regulated assemblies.

Why Choose N80C286-16TR?

The N80C286-16TR delivers a straightforward, industrial-grade 16-bit processing solution based on the Am80286 series from Advanced Micro Devices. Its combination of a 16 MHz 80C286 core, 5 V I/O, PLCC surface-mount packaging, and support for an 80C287 math co‑processor makes it suitable for embedded and industrial designs that require a proven 16-bit MPU footprint and extended temperature operation.

Engineers and procurement teams specifying the N80C286-16TR benefit from a clearly defined feature set—industrial grade temperature range, compact PLCC package, and RoHS compliance—making it a practical choice for maintaining or upgrading systems that rely on the Am80286 architecture.

Request a quote or submit a pricing inquiry today to get availability and lead-time information for the N80C286-16TR. Our team can provide the details you need to evaluate this part for your next embedded or industrial design.
