A3PN020-1QNG68

The A3PN020-1QNG68 is a ProASIC3 nano FPGA manufactured by Microchip Technology. It provides a programmable logic solution with approximately 20,000 gates implemented across 520 logic elements, and supports up to 49 user I/O pins.

Packaged in a compact 68-VFQFN with exposed pad and specified for surface-mount assembly, this commercial-grade device operates from 1.425 V to 1.575 V and across an operating temperature range of -20 °C to 85 °C, making it suitable for space-constrained, low-voltage digital designs.

Key Features

• Logic Capacity  Approximately 20,000 gates implemented using 520 logic elements, enabling modest complexity programmable logic designs.
• I/O Count  Up to 49 user I/O pins to interface with peripheral devices and system signals.
• Memory  No on-chip RAM (Total Ram Bits: 0), suitable for designs that use external memory or do not require embedded RAM.
• Power  Low-voltage core operation with a supply range of 1.425 V to 1.575 V for power-conscious designs.
• Package & Mounting  68-VFQFN exposed pad (supplier package: 68-QFN, 8×8) in a surface-mount form factor for compact PCB layouts and thermal grounding via the exposed pad.
• Temperature Range  Commercial operating range from -20 °C to 85 °C for typical commercial electronics environments.
• Compliance  RoHS compliant.

Typical Applications

• Compact digital logic  Implement glue logic, protocol translation, or control state machines where up to 49 I/O and ~20,000 gates meet system requirements.
• Low-voltage system designs  Integrate programmable logic into systems that operate within the 1.425 V to 1.575 V core voltage window.
• Space-constrained PCBs  Use the 68-VFQFN exposed pad package for dense board layouts and improved thermal contact in small form-factor designs.

Unique Advantages

• Balanced logic density: 520 logic elements and ~20,000 gates provide a trade-off between capability and device footprint for many mid-range programmable tasks.
• Compact package with thermal pad: The 68-VFQFN exposed pad reduces PCB area while offering a solderable thermal return for heat dissipation.
• Low-voltage operation: Narrow supply range (1.425–1.575 V) supports power-optimized designs and predictable core behavior.
• Commercial temperature suitability: Rated for -20 °C to 85 °C to meet typical commercial product environments.
• RoHS compliant: Aligns with standard environmental and manufacturing requirements.

Why Choose A3PN020-1QNG68?

The A3PN020-1QNG68 offers a compact, low-voltage FPGA option with a clear set of capabilities—approximately 20,000 gates across 520 logic elements and up to 49 I/O—housed in a 68-VFQFN exposed pad package. Its specification set targets designers who need moderate programmable logic capacity with a small footprint and surface-mount package.

Backed by Microchip Technology, this commercial-grade device provides predictable operating ranges and RoHS compliance, making it a practical choice for teams focused on compact digital logic implementations and low-voltage system integration.

Request a quote or submit a pricing and availability inquiry for the A3PN020-1QNG68 to receive more information and support for your design and procurement needs.
