A54SX32A-1CQ84M

The A54SX32A-1CQ84M is a HiRel SX-A family Field Programmable Gate Array (FPGA) from Microchip Technology designed for military-grade, high-reliability applications. It integrates 48,000 system gates and 2,880 logic elements in an 84-pin ceramic CQFP package with exposed pad and tie bar, delivering a compact programmable fabric for mission-critical embedded systems.

With a wide supply range and full military temperature qualification, this device is targeted at defense, aerospace and other harsh-environment systems that require deterministic timing, security features and QML-level manufacturing flow.

Key Features

• Logic Capacity — 48,000 system gates and 2,880 logic elements provide the programmable resources needed for medium-complexity FPGA functions.
• Flip-Flops / Register Resources — Dedicated flip-flop resources are provided as part of the SX-A family architecture to support synchronous logic (refer to family datasheet for device-specific flip-flop counts).
• I/O — 69 user I/O pins in the 84‑pin CQFP package, suitable for a range of external interfaces and signal routing in compact board designs.
• Performance (HiRel SX-A Family) — Family datasheet specifies up to 215 MHz system performance and 5.3 ns clock‑to‑out at military temperature for SX‑A devices, supporting deterministic timing requirements.
• Voltage Range & I/O Compatibility — Supports a wide supply range of 2.25 V to 5.25 V to accommodate mixed-voltage board environments.
• Package & Mounting — 84‑pin ceramic CQFP (42 × 42 mm) with exposed pad and tie bar; surface-mount mounting type for PCB assembly.
• Temperature & Grade — Military grade with operating temperature range of −55 °C to +125 °C and QML-class manufacturing flow referenced in the family documentation.
• Security & Reliability (Family-Level) — SX‑A family features Actel Secure Programming Technology with FuseLock™ and QML certification referenced in the family datasheet for protection against reverse engineering and design theft.
• RoHS Compliant — Device is RoHS compliant.

Typical Applications

• Defense & Aerospace Systems — Military-grade temperature range and QML-class family documentation make this FPGA suitable for avionics, tactical electronics and mission systems requiring ruggedized components.
• Secure Embedded Control — Family security features such as FuseLock™ support designs that require protection of IP and anti‑tamper measures.
• High-Reliability Control Electronics — Deterministic timing performance and ceramic CQFP packaging are a fit for high-reliability control and data-path logic in harsh environments.
• Mixed‑Voltage Interface Designs — Wide supply range and family I/O flexibility support interfacing to 2.5 V–5 V systems and legacy logic levels.

Unique Advantages

• Military-Grade Qualification: Delivered in a ceramic 84‑CQFP package with a specified −55 °C to +125 °C operating range and documented MIL‑STD‑883 product flow in the family datasheet.
• Compact, Mid‑Range Capacity: 48,000 system gates and 2,880 logic elements strike a balance between integration and board-space efficiency for moderate-complexity designs.
• Wide Supply Flexibility: Operates from 2.25 V to 5.25 V, enabling use in mixed-voltage systems without special power sequencing.
• Security-Focused Family Features: SX‑A family security mechanisms (FuseLock™) help protect design IP and prevent reverse engineering.
• Rugged Packaging: Ceramic CQFP with exposed pad and tie bar supports thermal performance and mechanical stability required by high-reliability assemblies.

Why Choose A54SX32A-1CQ84M?

The A54SX32A-1CQ84M combines mid-range programmable capacity with military-grade qualification and a robust ceramic package, making it well suited for defense, aerospace and other rugged embedded systems. Its allocation of 2,880 logic elements and 48,000 system gates provides the resources to implement control, interfacing and data-path logic in a compact footprint.

Backed by the SX‑A family’s documented features—security provisions, deterministic timing parameters and a QML-class production flow—this device delivers a durable, verifiable platform for long-life projects that demand sustained performance across extreme temperatures and strict manufacturing requirements.

Request a quote or submit an inquiry to receive pricing, availability and further technical support for the A54SX32A-1CQ84M.
