EP1C4F400C8

The EP1C4F400C8 is an Intel Cyclone® field programmable gate array (FPGA) device built on the Cyclone family architecture. This device provides 4,000 logic elements, approximately 78 Kbits of embedded RAM, and up to 301 user I/O pins in a compact 400‑BGA package.

Designed for data‑path and general embedded logic applications, the EP1C4F400C8 combines on‑chip memory and programmable logic with dedicated clocking resources and a broad set of I/O options to support external memory interfaces and system interconnects. It is supplied in a surface‑mount 400‑FBGA (21×21) package and rated for commercial temperature operation.

Key Features

• Core Logic  4,000 logic elements provide a mid‑density programmable fabric suitable for a wide range of custom logic and control functions.
• Embedded Memory  Approximately 78 Kbits (78,336 total RAM bits) of on‑chip RAM organized into M4K blocks for data buffering and small memory structures.
• I/O Capacity & Standards  Up to 301 user I/O pins enable dense external connectivity. The Cyclone family supports common I/O standards including LVTTL, LVCMOS, SSTL, and LVDS (family data).
• Clocking  Device architecture includes up to two phase‑locked loops (PLLs) for clock multiplication and phase control, supporting common clocking needs (family data).
• Packaging & Mounting  400‑BGA package (supplier device package: 400‑FBGA, 21×21) designed for surface‑mount assembly, enabling compact board layouts.
• Power  Core supply voltage range specified at 1.425 V to 1.575 V to match Cyclone-family power requirements.
• Operating Range & Grade  Commercial grade with an operating temperature range of 0 °C to 85 °C and RoHS compliance for environmental compatibility.

Typical Applications

• Data‑path processing  Use the programmable logic and on‑chip RAM to implement customized data processing pipelines and buffering in communications and signal‑processing tasks.
• Memory interface and bridging  The device supports external memory interfaces (family-level support for DDR SDRAM and other memories), making it suitable for memory controller logic and protocol bridging.
• ASSP/ASIC interfacing and prototyping  With up to 301 I/O pins and support for common I/O standards, the device can interface with ASSP/ASIC devices and serve in prototype or system glue logic roles.
• Embedded control and I/O‑rich systems  Combine logic elements and abundant I/O to implement control engines, sensor interfaces, and custom peripheral handling in compact designs.

Unique Advantages

• Right‑sized logic and memory: 4,000 logic elements and ~78 Kbits of embedded RAM deliver a balanced resource set for mid‑range FPGA designs without excess complexity.
• High I/O density: Up to 301 user I/O pins enable extensive external connectivity for interfaces, buses, and peripherals.
• On‑chip clocking resources: Integrated PLLs provide flexible clocking options to support multi‑clock designs and timing adjustments.
• Compact BGA footprint: The 400‑FBGA (21×21) package supports dense PCB layouts while maintaining surface‑mount compatibility.
• Commercial temperature and RoHS compliance: Commercial grade operation (0 °C to 85 °C) and RoHS compliance support standard electronic product requirements.

Why Choose EP1C4F400C8?

The EP1C4F400C8 provides a practical balance of programmable logic, embedded memory, and I/O capacity in a compact 400‑BGA package, making it well suited for designers implementing mid‑density custom logic, memory interfaces, and system glue logic. Its Cyclone family architecture includes features such as integrated PLLs and support for common I/O standards that simplify clocking and external connectivity.

As a commercially graded, RoHS‑compliant FPGA with a defined core supply range and clear package options, the EP1C4F400C8 is a dependable choice for projects that require predictable electrical and thermal operating conditions and a mature family architecture for migration and design reuse.
