MC68LC060RC66

The MC68LC060RC66 from NXP Semiconductors is a member of the MC68LC060 series: a single-core, 32-bit M68060-family microprocessor delivered in a 206-pin PGA package. It operates at 66 MHz and provides a compact, through-hole solution for embedded designs requiring a 32-bit processor core and standard serial communications.

This device targets embedded and legacy systems where a 66 MHz 68060-class processor, 3.3 V I/O and a 206-PGA form factor are required. It is RoHS compliant and rated for operation from 0 °C to 70 °C.

Key Features

• Core: 68060 core processor implemented as a single 32-bit core, suitable for embedded M680x0-class applications.
• Performance: 66 MHz clock speed for deterministic processing in control and compute tasks.
• Power / I/O: 3.3 V I/O voltage level for compatibility with modern 3.3 V system logic.
• Package: 206-pin PGA package (Supplier Device Package: 206-PGA, 47.25×47.25 mm); Package case listed as 206-BPGA. Delivered for through-hole mounting.
• Interfaces: Includes SCI (Serial Communications Interface) for standard serial connectivity.
• Graphics: No graphics acceleration—focused on general-purpose embedded processing.
• Operating Temperature: Specified for 0 °C to 70 °C operation to match room-temperature embedded and industrial environments.
• Environmental Compliance: RoHS compliant.

Typical Applications

• Embedded Control Systems: Use as the main processor in control and automation units where a 32-bit M68060-class core at 66 MHz meets system timing requirements.
• Legacy System Maintenance: Suitable for board-level replacements or refurbishments of systems built around the M680x0 architecture.
• Industrial Instrumentation: Drives data acquisition and instrument control functions within the 0 °C to 70 °C operating range.
• Prototyping and Development: Through-hole 206-PGA mounting supports prototyping, evaluation, and repair workflows that require socketed or removable processors.

Unique Advantages

• Known M68060 Architecture: Implements the 68060 core processor, allowing designers familiar with the M680x0 family to leverage existing software and design expertise.
• 66 MHz Deterministic Clocking: Provides predictable single-core performance suitable for time-critical embedded tasks.
• 3.3 V I/O Compatibility: Matches common modern logic levels, simplifying interfacing with 3.3 V peripherals and buses.
• Through-Hole 206-PGA Packaging: The 206-pin PGA form factor (47.25×47.25 mm) supports socketed installation and ease of replacement during maintenance or development.
• Simple Serial Connectivity: On-chip SCI interface for standard serial communications without additional interface ICs.
• RoHS Compliant: Meets lead-free environmental requirements for current manufacturing standards.

Why Choose MC68LC060RC66?

MC68LC060RC66 positions itself as a practical 32-bit microprocessor solution in the MC68LC060 series for embedded and legacy M680x0 applications. With a 66 MHz single 68060 core, 3.3 V I/O, SCI interface, and a 206-PGA through-hole package, it fits designs that require a socketed processor footprint and known M680x0 architecture behavior.

This part is well suited for engineers and procurement teams maintaining or updating equipment built on the M680x0 family, or for development projects that benefit from through-hole PGA mounting and standard temperature rating. Its RoHS compliance supports contemporary manufacturing and regulatory requirements.

Request a quote or submit a parts availability request to receive pricing and lead-time information for the MC68LC060RC66.
