MC68LC060RC50

The MC68LC060RC50 from NXP Semiconductors is a single‑core 32‑bit microprocessor based on the 68060 core, operating at 50 MHz. It is supplied in a 206‑PGA package (47.25×47.25 mm) with through‑hole mounting for embedded system deployment and board‑level replacement.

Designed for embedded applications that use the M680x0 architecture, the device provides 3.3 V I/O compatibility and an integrated Serial Communications Interface (SCI) to support serial device connections. The part is RoHS‑compliant and rated for operation from 0 °C to 70 °C.

Key Features

• Core & Architecture Single 68060 core providing native M680x0‑series 32‑bit processing.
• Clock Speed 50 MHz operating frequency for embedded processing tasks.
• Power & I/O 3.3 V I/O voltage as specified for logic interfacing.
• Interfaces Integrated SCI (Serial Communications Interface) for serial peripheral connectivity.
• Package & Mounting 206‑PGA package (47.25×47.25 mm) in through‑hole format for straightforward board installation and replacement.
• Operating Temperature Rated for 0 °C to 70 °C operation.
• Regulatory RoHS‑compliant.
• Graphics No on‑chip graphics acceleration.

Typical Applications

• Embedded Systems General‑purpose processing in embedded products that utilize the M680x0 architecture.
• Industrial Controllers Control and sequencing tasks where a 32‑bit 50 MHz core and 3.3 V I/O are required.
• Legacy Platform Maintenance Replacement or maintenance of existing M680x0‑based hardware and systems.
• Serial Communication Devices Applications requiring serial device interfacing using the SCI interface.

Unique Advantages

• Single 32‑bit 68060 Core: Native M680x0 instruction support in a compact single‑core device.
• 3.3 V I/O Compatibility: Simplifies interfacing with low‑voltage logic domains.
• Through‑Hole 206‑PGA Package: Facilitates board‑level installation, replacement, and prototyping with a defined 47.25×47.25 mm footprint.
• RoHS‑Compliant Construction: Meets RoHS requirements for restricted substances.
• Documented MC68060 Family: Part of the MC68060 family with published user documentation for design reference.

Why Choose MC68LC060RC50?

The MC68LC060RC50 positions a single 68060 core, 50 MHz clock, and 3.3 V I/O in a through‑hole 206‑PGA package suitable for embedded designers maintaining or developing M680x0‑based systems. Its combination of package format and serial interface support makes it appropriate for board‑level replacement and serial communication tasks within the specified 0 °C to 70 °C range.

As a RoHS‑compliant member of the MC68LC060 family, the MC68LC060RC50 is supported by published MC68060 user documentation to assist integration into existing designs and platform maintenance efforts.

Request a quote or submit a purchase inquiry to receive pricing and availability information for the MC68LC060RC50.
