MC68LC060BRC66

The MC68LC060BRC66 is a single-core 32-bit 68060 microprocessor IC operating at 66 MHz, supplied by NXP Semiconductors as part of the MC68LC060 series. Designed for embedded and industrial applications, it combines a 68060 core with 3.3 V I/O compatibility and industrial qualification for use across temperature-variable environments.

Its 206-pin PGA package and through-hole mounting make it suitable for designs requiring a robust physical interface and serviceability, while the device’s documented family (MC68060 user documentation) supports system integration and validation.

Key Features

• Core and Architecture  Single 68060 core, 32‑bit processor suitable for embedded 68K architectures and legacy 680x0 designs.
• Clock Speed  66 MHz operating frequency for deterministic control and processing tasks.
• Voltage  3.3 V I/O support for compatibility with common embedded logic domains.
• Qualification & Temperature Range  Industrial-qualified device with an operating temperature range of −40 °C to 70 °C.
• Package and Mounting  206‑pin PGA package (supplier device package: 206‑PGA, 47.25×47.25 mm) with 206‑BPGA package case noted; designed for through‑hole mounting.
• Interfaces  Includes SCI (Serial Communication Interface) for serial control and peripheral connectivity.
• Graphics  No integrated graphics acceleration.
• Environmental  RoHS compliant.

Typical Applications

• Industrial Control Systems  Provides 32‑bit processing and industrial temperature qualification for embedded controllers and factory automation tasks.
• Embedded Instrumentation  Used in measurement and test equipment that require a robust through‑hole package and documented 68060 family support.
• Legacy 680x0 Platform Maintenance  Suitable for repair, refurbishment, or continuation designs that rely on the M68060 core and 68K architecture compatibility.
• Communications and Serial Control  SCI interface and 3.3 V I/O make the device appropriate for serial control and peripheral interfacing in embedded products.

Unique Advantages

• Industrial Qualification:  Designed for operation from −40 °C to 70 °C, supporting deployment in temperature-challenging embedded environments.
• Documented 68060 Family:  Part of the MC68LC060 series with accompanying MC68060 user documentation to aid integration and validation.
• Through‑Hole 206‑PGA Packaging:  206‑pin PGA form factor (47.25×47.25 mm) and through‑hole mounting simplify handling, prototyping, and board-level serviceability.
• 3.3 V I/O Compatibility:  Native 3.3 V I/O helps integrate the MCU into common modern logic domains without additional level shifting.
• Serial Interface Support:  SCI provides straightforward serial communication options for control and peripheral connectivity.
• RoHS Compliant:  Meets RoHS environmental requirements for regulated markets.

Why Choose MC68LC060BRC66?

The MC68LC060BRC66 positions itself as a reliable, industrially qualified 68060 microprocessor option for embedded designers who require a documented 32‑bit core running at 66 MHz with 3.3 V I/O. Its through‑hole 206‑PGA packaging and industrial temperature range make it practical for applications where physical robustness and serviceability matter.

This part is suited to designers maintaining or extending 680x0‑based systems, implementing embedded instrumentation, or developing control systems that benefit from the MC68LC060 series documentation and industrial qualification. Its RoHS compliance and standard serial interface support help simplify regulatory and integration considerations.

If you would like pricing, availability, or to request a quote for the MC68LC060BRC66, submit an inquiry or quote request and include your quantity and delivery requirements.
