MC68LC040FE25A

The MC68LC040FE25A is a 32-bit M68040-family microprocessor in the MC68LC040 derivative, delivering a single-core integer processor running at 25 MHz. It is supplied in a 184-pin CQFP package (31.3 × 31.3 mm) and is designed for embedded system applications that require a compact, surface-mount 680x0-class MPU.

This device operates with 5 V I/O, includes an SCI serial interface, and is RoHS compliant. The MC68LC040 variant is documented in the M68040 user manual and programmer’s reference materials and omits the floating-point unit present in some other M68040 derivatives, making it suitable for integer-focused embedded designs.

Key Features

• Core Architecture A single 68040-class integer core with a 32-bit data path, targeting embedded applications that leverage the M680x0 architecture.
• Operating Frequency 25 MHz clock rate providing deterministic processing performance for legacy and embedded workloads.
• Voltage and I/O 5 V I/O signaling compatible with existing 5 V system environments.
• Package & Mounting 184-pin CQFP (31.3 × 31.3 mm) surface-mount package for board-level integration in compact embedded designs.
• Serial Communications Interface (SCI) On-chip SCI support for serial data exchange and peripheral communications.
• Operating Range & Compliance Rated for 0 °C to 70 °C operation and RoHS compliant for ease of integration into modern assemblies.
• Documentation Supported by the M68040 user manual and family programmer’s reference manual, providing thorough programming and implementation guidance.

Typical Applications

• Embedded Systems Core processing for embedded control units and single-board systems based on the M680x0 architecture.
• Legacy System Maintenance Board-level replacements and refurbishment projects that require a compatible 68040-class MPU in a compact CQFP footprint.
• Serial Communications Controllers Systems that leverage the on-chip SCI interface for device-to-device or peripheral communications.
• Industrial and Instrumentation Integer-focused control and monitoring applications operating within the device’s 0 °C to 70 °C temperature range and 5 V I/O domain.

Unique Advantages

• Integer-focused 68040 derivative: The MC68LC040 variant omits the floating-point unit, simplifying integration for integer-centric embedded designs.
• Compact surface-mount package: 184-CQFP (31.3 × 31.3 mm) offers a high-pin-count footprint while remaining suitable for dense PCB layouts.
• 5 V I/O compatibility: Maintains compatibility with established 5 V system architectures and legacy peripherals.
• On-chip serial interface (SCI): Integrated SCI reduces external component count for serial communication functions.
• RoHS compliant: Aligns with current environmental requirements for electronic assemblies.
• Comprehensive documentation: Supported by the M68040 user manual and family programmer’s reference manual for implementation and software development.

Why Choose MC68LC040FE25A?

The MC68LC040FE25A positions itself as a practical, well-documented 68040-family microprocessor for embedded and legacy M680x0 designs. With a 32-bit single-core architecture, 25 MHz operation, and 5 V I/O in a 184-CQFP surface-mount package, it fits applications that require a compact, integer-focused MPU with serial communication capability.

Engineers and procurement teams benefit from the device’s RoHS compliance, established M68040 documentation, and straightforward integration into existing 5 V embedded platforms, delivering a reliable option for maintenance, upgrade, and new designs that rely on the M680x0 architecture.

Request a quote or submit an inquiry to purchase the MC68LC040FE25A for your next embedded or legacy system project.
