MC68LC060RC75

The MC68LC060RC75 is a 32-bit microprocessor in the MC68LC060 series, featuring a single 68060 core running at 75 MHz. Packaged in a 206-pin PGA (47.25 × 47.25 mm) and designed for through-hole mounting, this device targets embedded applications that require a compact, documented 680x0-class CPU solution.

Key attributes include a 75 MHz core clock, 3.3 V I/O signaling, serial communications via SCI, and RoHS compliance. The M68060 user documentation covers the MC68060, MC68LC060 and MC68EC060 devices for design reference and integration guidance.

Key Features

• Core and Performance 68060 core, single 32-bit processor running at 75 MHz for general-purpose embedded processing.
• Power and I/O 3.3 V I/O voltage compatible with modern embedded system signaling.
• Package and Mounting 206-PGA package (47.25 × 47.25 mm) supplied for through-hole mounting, facilitating prototyping and board-level replacement designs.
• Interfaces Includes SCI serial interface for standard serial communication needs in embedded systems.
• Operating Range Rated for operation from 0 °C to 70 °C, suitable for commercial-temperature embedded applications.
• Environmental Compliance RoHS compliant to support environmentally conscious designs and regulatory requirements.
• Documentation Covered by the M68060 User’s Manual, which includes information for the MC68060, MC68LC060 and MC68EC060 devices to aid system integration.

Typical Applications

• Embedded Control Use as the main processing element in industrial or equipment controllers requiring a 32-bit 680x0-class CPU.
• Communications Equipment Implement serial protocol handling and control tasks using the onboard SCI interface and 3.3 V I/O.
• Instrument Control Drive measurement and instrumentation logic where through-hole PGA mounting and documented operation simplify development and testing.

Unique Advantages

• Established 68060 Core: Provides a known 32-bit instruction set and architecture for designs that rely on M680x0-class processing.
• Standard 3.3 V I/O: Facilitates integration with contemporary peripheral devices and logic levels.
• Through-Hole 206-PGA Packaging: Simplifies prototyping, rework and board-level replacement compared with surface-mount-only packages.
• Serial Communication (SCI): Built-in SCI support enables straightforward serial links for control, telemetry or configuration tasks.
• Commercial Temperature Rating: Operates across 0 °C to 70 °C to meet commercial embedded deployment requirements.
• RoHS Compliant: Meets environmental compliance expectations for product lifecycles and manufacturing.

Why Choose MC68LC060RC75?

The MC68LC060RC75 positions itself as a documented, single-core 32-bit microprocessor option for embedded developers who need a 75 MHz 68060-class CPU in a through-hole 206-PGA package. Its 3.3 V I/O, SCI interface and RoHS compliance make it suitable for a range of commercial embedded control, communications and instrumentation projects.

With supporting documentation in the M68060 User’s Manual and clear electrical and temperature specifications, this device is appropriate for designs that require a known 680x0 architecture, straightforward integration, and a supply-chain-friendly package form factor.

If you would like pricing or availability information, request a quote or submit an RFQ and our team will respond with the next steps for procurement and technical support.
