MIMX8UX6AVLFZAC

The MIMX8UX6AVLFZAC is a microprocessor from the NXP i.MX 8UX series designed for embedded and infotainment applications. It combines a heterogeneous core architecture featuring ARM® Cortex®-A53 and ARM® Cortex®-M4F processors in a 3-core, 64-bit configuration to handle application processing alongside real-time tasks.

Factory documentation for the i.MX8X family highlights integrated graphics and video subsystems, multi‑display support, and advanced audio processing, enabling multimedia-rich embedded platforms with compact surface-mount package options and RoHS compliance.

Key Features

• CPU Architecture  ARM® Cortex®-A53 and ARM® Cortex®-M4F cores in a 3-core, 64-bit configuration for combined application and real-time processing.
• Graphics & Video  Graphics acceleration is supported; the series documentation describes separate GPU and VPU subsystems and a failover-ready display controller for multimedia and display-rich designs.
• Audio & DSP  Series documentation references a high-performance Tensilica® HiFi 4 DSP for advanced audio preprocessing and voice recognition tasks.
• Memory Interfaces  Data sheet notes support for LPDDR4 and DDR3L memory interfaces to match a range of performance and cost targets.
• Multi‑Display Support  The family supports up to three displays with multiple output options (including parallel, MIPI‑DSI, and LVDS) for flexible HMI and multimedia implementations.
• Package Options  Available package outlines include 21 × 21 mm and 17 × 17 mm FCPBGA options with 0.8 mm pitch, suitable for compact surface-mount assemblies.
• Mounting & Compliance  Surface-mount device construction and RoHS compliance are specified for assembly and regulatory alignment.
• Comprehensive Technical Data  Detailed datasheet coverage includes electrical characteristics, PLL and oscillator details, I/O timing, ADC, boot configuration, and package pin assignments to support design and validation.

Typical Applications

• Infotainment and Multimedia Platforms  Leverages graphics/video acceleration, multi‑display capability, and audio DSP for rich user interfaces and media playback systems.
• Embedded HMI Systems  Combines application and real-time cores with display and I/O support to drive interactive control panels and operator interfaces.
• Advanced Audio Processing  Uses the integrated DSP and ARM cores for preprocessing, postprocessing, and voice recognition in voice-enabled products.
• Multi‑display Embedded Solutions  Supports systems requiring multiple simultaneously driven displays with flexible output options.

Unique Advantages

• Heterogeneous Multicore Design:  ARM® Cortex®-A53 plus Cortex®-M4F enables separation of application-level workloads and real-time control tasks for deterministic performance.
• Integrated Multimedia Subsystems:  Dedicated GPU and VPU subsystems plus a display controller reduce external component count for graphics and video functions.
• Flexible Memory Support:  LPDDR4 and DDR3L interface options allow designers to balance performance and cost across target applications.
• Compact Package Choices:  21 × 21 mm and 17 × 17 mm FCPBGA package outlines with 0.8 mm pitch provide options for space-constrained board designs.
• Extensive Documentation:  The supplied technical documentation includes electrical characteristics, boot-mode configuration, peripheral timing, and package assignments to accelerate system bring-up.
• RoHS Compliant:  Meets RoHS requirements for environmentally compliant manufacturing.

Why Choose MIMX8UX6AVLFZAC?

The MIMX8UX6AVLFZAC positions itself as a versatile embedded microprocessor within the i.MX 8UX family, combining multi-core ARM processing with dedicated multimedia and audio subsystems. This combination supports designs that require concurrent application processing, real-time control, and rich user interfaces.

Its flexible memory interfaces, multi‑display capabilities, and compact BGA package options make it well-suited for embedded and infotainment-oriented platforms where integration, documented electrical characteristics, and space-optimized mounting are important design considerations.

Request a quote or submit an inquiry to check availability, lead times, and pricing for the MIMX8UX6AVLFZAC. Our team can provide the latest purchasing information and assist with your design requirements.
