10AX048H1F34E1SG

The 10AX048H1F34E1SG is an Arria 10 GX series FPGA—part of Intel's 20 nm mid-range, high-performance, power-efficient device family. This device combines large logic capacity and on-chip memory with a high I/O count to address midrange applications that require performance and power efficiency.

With 480,000 logic elements, 5,664,768 total RAM bits and 492 I/O, this surface-mount 1152‑FCBGA (35×35) package is offered in Extended grade, operates from 0 °C to 100 °C, and requires a core voltage supply in the 870 mV to 980 mV range. Family-level features include variable-precision DSP blocks, advanced clocking and PLL resources, and support for high-speed serial interfaces and industry-standard hard IP.

Key Features

• Core Capacity  480,000 logic elements to implement large, complex digital designs and custom processing pipelines.
• Embedded Memory  5,664,768 total RAM bits for on-chip buffering, frame storage, and state retention.
• I/O and Package  492 general-purpose I/Os in an 1152‑FCBGA (35×35) package; surface-mount mounting for standard PCB assembly.
• Power and Voltage  Core supply voltage range 870 mV to 980 mV, enabling optimized core power delivery and low-voltage operation.
• Thermal & Grade  Extended grade device with an operating temperature range of 0 °C to 100 °C for demanding midrange environments.
• High-speed Interfaces (device family)  Arria 10 GX devices support low-power serial transceivers, PCIe Gen1/Gen2/Gen3 hard IP, and 10 Gbps Ethernet/Interlaken PCS hard IP (family-level capability documented in the device overview).
• DSP and Clocking (device family)  Variable-precision DSP blocks and comprehensive clock networks with PLL clock sources for precise timing and signal processing (family-level features).
• Standards and Compliance  RoHS compliant packaging and materials.

Typical Applications

• Wireless Infrastructure  Channel and switch cards, remote radio head functions, and mobile backhaul components that require high-throughput, low-power programmable logic.
• Wireline & Optical Networking  40G/100G line cards, muxponders and transponders, and aggregation/bridging functions leveraging on-chip memory and high-speed serial interfaces.
• Broadcast & Professional AV  Studio switches, transport systems, and video processing pipelines that benefit from large logic capacity and embedded RAM.
• Computing & Storage  Server acceleration, flash cache controllers, and cloud infrastructure modules that use FPGA-based acceleration and custom I/O handling.
• Medical and Defense Systems  Diagnostic imaging, radar, electronic warfare, and secure communications applications that require configurable logic and deterministic hardware processing.

Unique Advantages

• Substantial on-chip resources: 480,000 logic elements and over 5.6 Mbit of RAM provide the density needed to consolidate multiple functions into a single device, reducing BOM and board complexity.
• High I/O count in a compact package: 492 I/Os in a 1152‑FCBGA (35×35) package supports rich external interfacing while maintaining a compact PCB footprint.
• Family-level high-speed connectivity: Support for PCIe and multi‑Gbps serial protocols (documented for Arria 10 GX family) enables integration of standard high-speed links without external PHYs.
• Optimized power rails: A defined core voltage range (870–980 mV) allows careful power budgeting and optimization for power-sensitive designs.
• Extended grade and RoHS compliance: Extended device grade and RoHS-compliant materials support deployment in a wide range of commercial and industrial environments.

Why Choose 10AX048H1F34E1SG?

This Arria 10 GX FPGA balances large programmable logic capacity, abundant on-chip memory, and a high I/O count in a compact 1152‑FCBGA package—making it well suited for midrange applications that need performance and flexibility. The device’s family-level support for advanced DSP resources, clocking, and high‑speed serial/hard IP interfaces gives designers a scalable platform for accelerated signal processing, networking, and system integration.

For engineering teams and procurement focused on deployable, programmable hardware with clear electrical and thermal parameters (870–980 mV core supply, 0 °C to 100 °C operating range), this part provides a measurable foundation for building robust, scalable systems backed by documented Arria 10 device capabilities.

Request a quote or submit a pricing and availability inquiry to begin evaluating the 10AX048H1F34E1SG for your design.
