5AGXBA1D4F27C4N
| Part Description |
Arria V GX Field Programmable Gate Array (FPGA) IC 336 8666112 75000 672-BBGA, FCBGA |
|---|---|
| Quantity | 42 Available (as of May 5, 2026) |
| Product Category | Field Programmable Gate Array (FPGA) |
|---|---|
| Manufacturer | Intel |
| Manufacturing Status | Obsolete |
| Manufacturer Standard Lead Time | RFQ |
| Datasheet |
Specifications & Environmental
| Device Package | 672-FBGA (27x27) | Grade | Commercial | Operating Temperature | 0°C – 85°C | ||
|---|---|---|---|---|---|---|---|
| Package / Case | 672-BBGA, FCBGA | Number of I/O | 336 | Voltage | 1.07 V - 1.13 V | ||
| Mounting Method | Surface Mount | RoHS Compliance | RoHS Compliant | REACH Compliance | REACH Unknown | ||
| Moisture Sensitivity Level | 3 (168 Hours) | Number of LABs/CLBs | 3537 | Number of Logic Elements/Cells | 75000 | ||
| Number of Gates | N/A | ECCN | 3A001A2C | HTS Code | 8542.39.0001 | ||
| Qualification | N/A | Total RAM Bits | 8666112 |
Overview of 5AGXBA1D4F27C4N – Arria V GX FPGA, 75,000 logic elements, 336 I/Os
The 5AGXBA1D4F27C4N is an Intel Arria V GX field-programmable gate array (FPGA) in a 672-ball BGA package designed for commercial-grade programmable-logic designs. It combines 75,000 logic elements with 8,666,112 bits of on-chip RAM and 336 user I/O to support complex, high-density logic and memory integration within surface-mount PCB assemblies.
This device targets commercial electronic systems that require substantial programmable logic capacity, significant embedded RAM, and a high pin-count package while operating within a 1.07 V–1.13 V core supply range and a 0 °C to 85 °C commercial temperature window.
Key Features
- Core Logic 75,000 logic elements for implementing complex digital logic and custom accelerators.
- Embedded Memory 8,666,112 total RAM bits to support on-chip buffering, lookup tables, and state storage.
- I/O Density 336 user I/O pins to enable extensive peripheral interfacing and board-level connectivity.
- Package and Mounting 672-ball BGA (672-FBGA, 27×27) surface-mount package for high-density PCB integration.
- Power Core voltage supply range of 1.07 V to 1.13 V for defined power delivery planning.
- Operating Range Commercial operating temperature range from 0 °C to 85 °C.
- Compliance RoHS-compliant construction to meet standard environmental requirements.
Typical Applications
- Commercial networking and communications equipment Use the device’s high logic density and 336 I/O for protocol processing, packet handling, or interface bridging in commercial systems.
- High-density data buffering and processing Leverage 8.66 Mbit of on-chip RAM for buffering, data path staging, and local memory-intensive tasks.
- Multi-I/O control and prototyping platforms Deploy the 672-FBGA package for compact, surface-mount designs that need many external interfaces.
Unique Advantages
- Substantial programmable capacity: 75,000 logic elements enable complex logic implementations and custom digital functions without external programmable resources.
- Large on-chip RAM: 8,666,112 bits of RAM reduce dependence on external memory for many buffering and lookup tasks, simplifying BOM and layout.
- High I/O count: 336 I/Os provide flexibility for parallel interfaces, multi-channel designs, and rich peripheral connectivity.
- Board-level integration: The 672-ball FBGA (27×27) surface-mount package supports compact, high-density PCB implementations.
- Commercial-grade readiness: Rated for 0 °C to 85 °C operation and RoHS-compliant, suitable for a wide range of commercial electronic products.
- Predictable power planning: Defined core supply window (1.07 V–1.13 V) simplifies power-supply design and verification.
Why Choose 5AGXBA1D4F27C4N?
The 5AGXBA1D4F27C4N positions itself as a high-capacity, commercial-grade Arria V GX FPGA that balances large programmable logic resources, substantial on-chip RAM, and a broad I/O complement in a compact 672-ball BGA package. Its defined core voltage range and commercial temperature rating make it straightforward to integrate into commercial systems that demand dense logic, memory, and interface capability.
This part is well suited to engineers and procurement teams developing commercial networking, data-processing, and interface-rich products who need a scalable, on-board programmable logic device with significant embedded RAM and a high pin count for complex board-level designs.
Request a quote or submit an inquiry to receive pricing and availability information for 5AGXBA1D4F27C4N or to discuss how this Arria V GX FPGA fits your next commercial design.
