5AGXMA1D4F27C5N

IC FPGA 336 I/O 672FBGA
Part Description

Arria V GX Field Programmable Gate Array (FPGA) IC 336 8666112 75000 672-BBGA, FCBGA

Quantity 876 Available (as of October 8, 2026)
Product CategoryField Programmable Gate Array (FPGA)
ManufacturerIntel
Manufacturing StatusObsolete
Manufacturer Standard Lead TimeContact Us
Datasheet

Specifications & Environmental

Device Package672-FBGA (27x27)GradeCommercialOperating Temperature0°C – 85°C
Package / Case672-BBGA, FCBGANumber of I/O336Voltage1.07 V - 1.13 V
Mounting MethodSurface MountRoHS ComplianceRoHS CompliantREACH ComplianceREACH Unknown
Moisture Sensitivity Level3 (168 Hours)Number of LABs/CLBs3537Number of Logic Elements/Cells75000
Number of GatesN/AECCN3A001A2CHTS Code8542.39.0001
QualificationN/ATotal RAM Bits8666112

Overview of 5AGXMA1D4F27C5N – Arria V GX FPGA, 75,000 logic elements, 672‑BBGA

The 5AGXMA1D4F27C5N is an Arria V GX Field Programmable Gate Array (FPGA) in a commercial grade surface‑mount package. It integrates 75,000 logic elements, approximately 8.67 Mbits of on‑chip RAM, and 336 I/Os to support high‑density, high‑I/O designs within a 672‑ball BGA (FCBGA) footprint.

This device is suitable for designs that require substantial logic capacity, significant embedded memory, and a large number of I/O signals while operating within a commercial temperature range and a defined core supply window.

Key Features

  • Core Capacity — 75,000 logic elements for implementing complex digital logic and control functions.
  • Embedded Memory — Total on‑chip RAM of 8,666,112 bits (approximately 8.67 Mbits) to support buffering, lookup tables, and data storage on device.
  • I/O Resources — 336 dedicated I/O pins to interface with peripherals, sensors, and external memory or logic devices.
  • Package and Mounting — 672‑BBGA (FCBGA) package; supplier device package listed as 672‑FBGA (27×27); surface‑mount mounting type for compact PCB integration.
  • Voltage Supply — Core operating supply range of 1.07 V to 1.13 V, enabling predictable power planning at the FPGA core level.
  • Operating Temperature — Commercial temperature grade with an operating range of 0 °C to 85 °C for standard commercial applications.
  • RoHS Compliant — Meets RoHS environmental requirements for lead‑free assembly.

Typical Applications

  • High‑density digital designs — For projects that require up to 75,000 logic elements to implement complex programmable logic and control.
  • Memory‑intensive functions — Suited to designs needing approximately 8.67 Mbits of embedded RAM for buffering, LUTs, and on‑chip storage.
  • I/O‑centric systems — Use where a large number of external interfaces or parallel signals are needed, leveraging 336 I/Os.
  • Compact board designs — Fits applications constrained by board space that can accommodate a 672‑ball BGA surface‑mount package (27×27).

Unique Advantages

  • Substantial logic density: 75,000 logic elements provide headroom for complex logic implementation without multiple devices.
  • Significant on‑chip RAM: Approximately 8.67 Mbits of embedded memory reduces dependence on external RAM for many buffering and storage tasks.
  • Extensive I/O count: 336 I/Os simplify system partitioning and reduce the need for external I/O expanders.
  • Defined core supply window: 1.07 V to 1.13 V specification helps with precise power sequencing and regulator selection.
  • Commercial temperature rating: Rated 0 °C to 85 °C for standard commercial deployments.
  • RoHS compliance: Supports lead‑free assembly and regulatory requirements for environmental compliance.

Why Choose 5AGXMA1D4F27C5N?

The 5AGXMA1D4F27C5N Arria V GX FPGA brings a balanced combination of logic capacity, embedded memory, and I/O resources in a compact 672‑BBGA surface‑mount package. Its defined core voltage range and commercial operating temperature make it suitable for designers seeking predictable electrical and thermal integration into mainstream products.

This device is a practical choice for engineering teams that need a single‑chip solution offering significant programmable logic and on‑chip RAM while maintaining a high I/O count and a compact PCB footprint.

Request a quote or submit an inquiry for pricing and availability of the 5AGXMA1D4F27C5N to evaluate it for your next design.
