A54SX32A-CQ84B

The A54SX32A-CQ84B is a HiRel SX-A family field programmable gate array (FPGA) in an 84-pin ceramic CQFP package with exposed pad and tie bar, delivered as a military-grade device. It provides a compact FPGA solution with 48,000 system gates and 2,880 logic elements for control, signal processing, and glue-logic functions in harsh-environment embedded systems.

Built for reliability in demanding temperature ranges and flexible voltage domains, this device is targeted at military and other high-reliability applications that require deterministic timing, robust I/O flexibility, and long-term stability.

Key Features

• Core Capacity — 48,000 system gates and approximately 2,880 logic elements provide programmable logic density suitable for complex control and signal routing tasks.
• User I/O — 69 I/O pins in the 84-pin CQFP package support mixed-voltage interfacing and flexible system connectivity.
• Military Temperature Range — 100% tested for operation from −55°C to +125°C, addressing high-reliability and ruggedized system requirements.
• Wide Supply Range — Operates across 2.25 V to 5.25 V, enabling integration with diverse legacy and modern voltage domains.
• Package and Mounting — 84-CQFP (42 × 42 mm) ceramic quad flat pack with exposed pad and tie bar; surface-mount mounting for PCB-level robustness.
• HiRel SX-A Family Features — Family-level capabilities include deterministic, user-controllable timing, boundary-scan (JTAG) support, and secure programming technology (FuseLock™) that helps protect designs from reverse engineering.
• High-Performance Timing (Family) — SX-A family performance metrics include up to 215 MHz system performance and 5.3 ns clock‑to‑out at military temperature grades.
• Qualification and Compliance — Classified as Military grade and supplied in a QML/Class B product flow with MIL-STD-883 screening and burn-in procedures (per family datasheet).
• Environmentally Compliant — RoHS compliant for regulated-material conformity.

Typical Applications

• Military & Defense Systems — Rugged, temperature‑rated FPGA logic for mission-critical control, signal processing, and interface conversion in tactical electronics.
• Avionics and Aerospace — Deterministic timing and high-reliability packaging suitable for avionics subsystems requiring ceramic packages and MIL temperature grades.
• Secure Embedded Systems — FuseLock™ secure programming and boundary-scan support help protect intellectual property and enable in-system testability.
• High-Reliability Instrumentation — Compact FPGA resources and wide supply tolerance make the device suitable for test, measurement, and rugged instrumentation designs.

Unique Advantages

• Designed for Harsh Environments: Military-grade screening and −55°C to +125°C operation provide confidence in extreme-temperature deployments.
• Flexible Voltage Integration: 2.25 V to 5.25 V supply range enables direct interfacing with a broad set of legacy and modern systems without complex level-shifting.
• Ceramic CQFP with Exposed Pad: Robust package construction with exposed pad and tie bar supports thermal dissipation and mechanical stability on high-reliability PCBs.
• Deterministic Timing Characteristics: SX-A family clock-to-out and internal performance metrics support designs requiring predictable, user-controllable timing.
• Security and Testability: Built-in secure programming and boundary-scan (JTAG) features simplify in-system verification and protect design IP.
• Regulatory and Environmental Compliance: RoHS compliance coupled with QML/Class B production flow aligns with regulated procurement and long-term program needs.

Why Choose A54SX32A-CQ84B?

The A54SX32A-CQ84B pairs a proven HiRel SX-A FPGA architecture with military-grade screening and a ceramic CQFP exposed-pad package to deliver a compact, robust programmable-logic solution. Its 48,000 system gates and 2,880 logic elements offer a practical balance of density and determinism for embedded systems that demand repeatable timing and secure configuration.

This device is well suited to engineers and programs requiring long-term reliability, secure in-system programming, and the ability to operate across a wide supply-voltage and temperature range. The combination of family-level performance characteristics, MIL-grade qualification steps, and RoHS compliance provides a clear value proposition for high-reliability applications.

Request a quote or submit an inquiry to receive pricing, availability, and lead-time information for the A54SX32A-CQ84B.
