EP20K400BC652-1

The EP20K400BC652-1 is an APEX-20K® field programmable gate array (FPGA) in a 652-BGA package, optimized for commercial-grade programmable-logic applications. It combines 16,640 logic elements, approximately 0.213 Mbits of embedded memory, and a high I/O count to address designs that require substantial on-chip logic and connectivity.

With a supply voltage range of 2.375 V to 2.625 V and an operating temperature range of 0 °C to 85 °C, this device is suited to commercial electronic systems requiring RoHS-compliant components in a surface-mount BGA footprint.

Key Features

• Core Logic  16,640 logic elements and approximately 1,052,000 gates provide substantial programmable logic capacity for custom digital functions.
• Embedded Memory  Total on-chip RAM of 212,992 bits (approximately 0.213 Mbits) for local storage and buffering within logic designs.
• I/O Density  502 I/O pins allow flexible interfacing and integration with external peripherals and subsystems.
• Packaging & Mounting  652-BGA package (652-BGA (45x45)) with surface-mount mounting type supports compact board-level integration and reliable soldering processes.
• Power  Nominal supply voltage range of 2.375 V to 2.625 V for core power planning and voltage-domain integration.
• Operating Range & Grade  Commercial-grade device rated for operation from 0 °C to 85 °C.
• Environmental Compliance  RoHS compliant to support regulatory and assembly requirements.

Typical Applications

• Embedded Systems  Use the FPGA’s 16,640 logic elements and on-chip RAM for custom digital processing, glue-logic, and control functions in commercial embedded products.
• Communications Equipment  High I/O count enables protocol interfacing, signal routing, and peripheral aggregation in communication and networking modules.
• Consumer and Commercial Electronics  Commercial-grade operating range and compact 652-BGA package suit product lines where board space and RoHS compliance are important.

Unique Advantages

• High Logic Density:  16,640 logic elements deliver significant on-chip programmable resources for complex logic implementations without immediate need for external glue logic.
• Substantial Embedded Memory:  Approximately 0.213 Mbits of RAM supports local buffering, state storage, and small lookup tables to reduce external memory dependencies.
• Generous I/O Count:  502 I/O pins enable broad peripheral connectivity and flexible board-level interfacing options.
• Compact BGA Footprint:  652-BGA (45x45) packaging with surface-mount mounting supports dense board layouts and automated assembly processes.
• Commercial-Grade Reliability:  Rated for 0 °C to 85 °C operation and RoHS compliance for standard commercial deployments and regulatory alignment.

Why Choose EP20K400BC652-1?

The EP20K400BC652-1 delivers a balanced combination of logic capacity, embedded memory, and high I/O density in a compact 652-BGA surface-mount package. Its commercial-grade temperature rating, RoHS compliance, and defined supply-voltage window make it suitable for a broad range of commercial electronic designs that require moderate to high programmable logic and flexible interfacing.

This FPGA is a practical choice for design teams looking to integrate substantial on-chip logic and memory while maintaining compact board layouts and compliance with common environmental requirements.

Request a quote or submit an inquiry today to discuss availability and pricing for the EP20K400BC652-1.
