XA7A50T-1CSG324Q

The XA7A50T-1CSG324Q is an Artix-7 XA Field Programmable Gate Array (FPGA) IC from AMD. It provides a mid-range programmable logic fabric with 52,160 logic elements and approximately 2.76 Mbits of on-chip RAM in a compact 324-ball CSPBGA/LFBGA package.

Designed and qualified for automotive use (AEC-Q100), this device supports operation across a wide temperature range and a low-voltage core supply, making it suitable for designs that require configurable logic, substantial embedded memory, and a large I/O count under demanding environmental conditions.

Key Features

• Logic Capacity 52,160 logic elements provide flexible programmable logic for mid-density designs.
• Embedded Memory Approximately 2.76 Mbits of total on-chip RAM to support buffering, state machines, and data processing.
• I/O Count 210 user I/Os to enable broad interfacing with sensors, controllers, and external peripherals.
• Automotive Qualification AEC-Q100 qualification and Automotive grade designation for use in automotive electronic applications.
• Power and Supply Core voltage supply specified at 0.95 V to 1.05 V to match system power-rail requirements.
• Operating Range Rated for operation from −40 °C to 125 °C to support thermally demanding environments.
• Package and Mounting Available in a 324-LFBGA / 324-CSPBGA package (supplier device package: 324-CSPBGA (15x15)) with surface-mount mounting type for compact board-level integration.
• Environmental Compliance RoHS compliant.

Typical Applications

• Automotive electronic control AEC-Q100 qualification and the −40 °C to 125 °C operating range make this FPGA suitable for automotive electronic control modules requiring configurable logic and on-chip memory.
• Embedded processing and control The combination of 52,160 logic elements and ~2.76 Mbits of RAM supports custom digital signal processing, protocol bridging, and control logic for embedded systems.
• I/O‑intensive aggregation With 210 I/Os, the device is well suited for designs that need to consolidate multiple sensor, actuator, or peripheral interfaces into a single programmable device.

Unique Advantages

• Automotive-qualified platform: AEC-Q100 qualification provides a pathway for deployment in automotive electronic designs requiring industry-recognized device qualification.
• Balanced logic and memory: 52,160 logic elements paired with approximately 2.76 Mbits of embedded RAM enable a wide range of mid-density programmable functions without external memory dependencies.
• High I/O density: 210 user I/Os reduce the need for additional interface components and simplify board-level routing for multi-signal systems.
• Compact, surface-mount packaging: 324-LFBGA / 324-CSPBGA packaging supports compact board layouts and high-density assembly processes.
• Wide thermal and low-voltage operation: Support for −40 °C to 125 °C operation and a 0.95–1.05 V core supply aligns with demanding system power and thermal requirements.
• Regulatory compliance: RoHS compliance supports environmentally restricted manufacturing and supply chains.

Why Choose XA7A50T-1CSG324Q?

The XA7A50T-1CSG324Q delivers a balanced mid-range FPGA option for engineers seeking programmable logic with substantial embedded memory, a large I/O count, and automotive-grade qualification. Its specification set — including 52,160 logic elements, approximately 2.76 Mbits of RAM, 210 I/Os, AEC-Q100 qualification, and extended temperature operation — positions it for designs that require reliable, configurable digital logic under stringent environmental conditions.

Backed by AMD’s Artix-7 XA family heritage, this device is suited for teams building scalable, robust systems where on-chip resources, automotive qualification, and compact packaging streamline integration and long-term deployment.

Request a quote or submit an inquiry to receive pricing and availability for the XA7A50T-1CSG324Q and to discuss how it fits your next automotive or embedded FPGA design.
