XC4VLX100-10FF1513I

The XC4VLX100-10FF1513I is a Virtex®-4 LX Field Programmable Gate Array (FPGA) IC from AMD. It provides a high-density programmable fabric with substantial on-chip RAM and a large I/O count in a 1513-ball FCBGA package, targeted at industrial-grade applications.

Designed for designs that require extensive logic resources, abundant I/O, and moderate on-chip memory, this device is suited for complex digital systems and dense interfacing requirements while operating across a wide industrial temperature range.

Key Features

• Core Logic  110,592 logic elements provide extensive programmable resources for implementing complex digital designs.
• Embedded Memory  Approximately 4.4 Mbits of embedded memory (4,423,680 total RAM bits) for buffering, state storage, and local data processing.
• I/O Capacity  960 user I/Os enable high-density external interfacing and parallel connectivity.
• Power  Specified supply voltage range of 1.14 V to 1.26 V for core operation.
• Package & Mounting  1513-BBGA, FCBGA package (supplier device package: 1513-FCBGA, 40×40) optimized for surface-mount PCB assembly.
• Temperature & Grade  Industrial-grade device rated for operation from -40 °C to 100 °C.
• Environmental Compliance  RoHS compliant.

Typical Applications

• High-density digital systems  Leverage the large logic element count and on-chip RAM to implement complex state machines, datapaths, and custom processing blocks.
• High-pin-count interfacing  The 960 I/Os support dense parallel interfaces, wide buses, and multiple peripheral connections for system integration.
• Industrial control and instrumentation  Industrial-grade temperature rating and robust packaging make it suitable for embedded controllers and instrumentation platforms requiring reliable operation.

Unique Advantages

• Highly integrated logic capacity: 110,592 logic elements reduce the need for multi-chip solutions and simplify system architecture.
• Substantial on-chip memory: Approximately 4.4 Mbits of embedded RAM supports local buffering and reduces external memory dependence.
• Extensive I/O resources: 960 I/Os enable flexible connectivity and support for multiple parallel interfaces without extensive multiplexing.
• Industrial temperature support: Rated from -40 °C to 100 °C for deployment in industrial environments.
• Compact FCBGA package: 1513-FCBGA (40×40) surface-mount package provides a high-density mounting footprint for space-constrained boards.
• Regulatory compliance: RoHS compliance supports environmental and manufacturing requirements.

Why Choose XC4VLX100-10FF1513I?

The XC4VLX100-10FF1513I combines large programmable logic resources, significant embedded memory, and a very high I/O count in a surface-mount FCBGA package, making it a strong choice for industrial designs that require complex digital logic and dense interfacing. Its specified supply voltage and industrial temperature rating provide predictable electrical and environmental behavior for deployed systems.

This device is well suited for engineering teams building scalable, high-density FPGA-based solutions that demand on-chip resources and robust operating range. Its combination of logic, memory, and I/O enables consolidation of functionality and reduction of external components in many embedded applications.

Request a quote or submit a pricing and availability inquiry to evaluate the XC4VLX100-10FF1513I for your next design.
