XC4VLX100-10FFG1513C

The XC4VLX100-10FFG1513C is a Virtex®-4 LX Field Programmable Gate Array (FPGA) in a 1513-FCBGA package. It combines a high count of configurable logic resources, substantial on-chip RAM, and a large I/O complement in a commercial-grade, surface-mount FCBGA footprint.

Key Features

• Logic Resources 12,288 CLBs and 110,592 logic elements provide a high density of programmable logic for complex digital designs.
• Embedded Memory Approximately 4.42 Mbits of on-chip RAM (4,423,680 bits) supports data buffering, state storage, and memory-intensive logic functions.
• I/O Count 960 user I/Os enable wide parallel connectivity for interfacing with peripherals, peripherals arrays, or multiple subsystems.
• Package and Mounting 1513-FCBGA (40×40) package case in a surface-mount form factor suitable for compact board designs.
• Power Core supply operating range from 1.14 V to 1.26 V for the device’s core voltage requirements.
• Temperature and Grade Commercial grade device with an operating temperature range of 0 °C to 85 °C.
• Compliance RoHS compliant.

Typical Applications

• Custom Digital Logic — Implement complex, application-specific logic and control functions using the device’s large pool of logic elements and CLBs.
• High-Density I/O Interfaces — Use the 960 I/Os for bridging multiple parallel interfaces or aggregating signals from sensor arrays and peripherals.
• On-chip Memory Storage — Leverage approximately 4.42 Mbits of embedded RAM for buffering, packet storage, or state machines within your design.

Unique Advantages

• High Logic Density: 12,288 CLBs and 110,592 logic elements enable implementation of complex, gate-rich designs without immediate upscaling.
• Significant Embedded Memory: Approximately 4.42 Mbits of on-chip RAM reduces reliance on external memory for many buffering and storage needs.
• Large I/O Count: 960 I/Os provide flexibility for multi-channel interfaces and high-parallelism architectures.
• Compact, Surface-Mount FCBGA: 1513-FCBGA (40×40) packaging supports compact PCB layouts while delivering high pin density.
• Defined Commercial Operating Range: Rated for 0 °C to 85 °C operation and commercial-grade use cases.
• RoHS Compliant: Conforms to RoHS environmental requirements.

Why Choose XC4VLX100-10FFG1513C?

The XC4VLX100-10FFG1513C positions itself as a high-capacity Virtex®-4 LX FPGA option for designs that require substantial programmable logic, abundant embedded RAM, and a large number of I/Os in a compact FCBGA package. Its defined core voltage range and commercial temperature rating make it suitable for a broad range of board-level applications where integration density and on-chip memory are priorities.

Designers and procurement teams seeking a scalable FPGA resource with measurable logic capacity, significant on-chip memory, and high I/O density will find this device appropriate for mid-to-high complexity digital systems. The RoHS compliance and surface-mount FCBGA packaging support modern manufacturing and assembly processes.

Request a quote or submit an inquiry to obtain pricing and availability for the XC4VLX100-10FFG1513C and to discuss how it fits your next FPGA-based design.
