MPC603RRX200TC

The MPC603RRX200TC is a single-core PowerPC 603e microprocessor manufactured by NXP Semiconductors for embedded applications. It implements the 32‑bit PowerPC 603e architecture and operates at 200 MHz, delivering balanced integer and floating-point processing for industrial and embedded systems.

Designed for low-power embedded designs and industrial environments, the device combines performance features such as superscalar execution and multiple power-saving modes with industrial-grade operating range and RoHS compliance.

Key Features

• Core and Architecture  PowerPC 603e 32‑bit core, single core implementation providing established PowerPC instruction-set compatibility.
• Performance  200 MHz core frequency with a superscalar design capable of issuing and retiring as many as three instructions per clock to increase instruction throughput.
• Execution Units  Integrates multiple execution units including an integer unit (IU), floating-point unit (FPU) and branch processing unit (BPU) to handle mixed workloads.
• Power Management  Four software-controllable power-saving modes (nap, doze, sleep and a dynamic power management mode) to reduce power dissipation during idle periods.
• Electrical  3.3 V I/O supply voltage, suitable for common embedded system voltage domains.
• Package and Mounting  255‑ball FCCBGA package (21 × 21) in a surface-mount form factor for compact system integration.
• Qualification and Temperature  Industrial qualification with an operating temperature range of −40 °C to 105 °C for deployment in demanding environments.
• Compliance  RoHS compliant.

Typical Applications

• Embedded control and automation  Single-core PowerPC processing with industrial temperature rating makes it suitable for controller and automation endpoints.
• Industrial instrumentation  Deterministic 32‑bit processing and extended temperature support for measurement and monitoring equipment.
• Communications and networking appliances  Balanced integer and floating-point capability for protocol handling and control-plane tasks in embedded networking gear.

Unique Advantages

• Balanced 32‑bit performance:  200 MHz PowerPC 603e core with superscalar execution provides predictable processing capacity for embedded workloads.
• Built‑in power management:  Multiple software-controllable low-power modes and dynamic power management help reduce energy consumption in duty‑cycled applications.
• Industrial readiness:  Qualification for industrial use and an operating range down to −40 °C up to 105 °C supports deployment in harsh conditions.
• Compact, surface‑mount package:  255‑ball FCCBGA (21×21) footprint enables high-density board designs and reliable solder attachment for production assemblies.
• Standards‑aligned architecture:  Implementation of the PowerPC 603e architecture provides a known instruction set and software portability for existing PowerPC‑based designs.
• Regulatory and environmental compliance:  RoHS compliance simplifies integration into products targeting global markets with restricted materials requirements.

Why Choose MPC603RRX200TC?

The MPC603RRX200TC delivers a proven 32‑bit PowerPC 603e core at 200 MHz within a compact FCCBGA package, combining predictable processing capability with on-chip power management features suited to embedded and industrial systems. Its industrial temperature range and RoHS compliance make it a practical choice where environmental robustness and regulatory conformance are required.

This part is well matched to designers seeking a single‑core PowerPC solution for control, instrumentation, and communications applications that benefit from integrated power-saving modes and a compact surface-mount package.

Request a quote or submit an inquiry for pricing and availability of the MPC603RRX200TC to receive product-specific ordering information and lead‑time details.
