SAM9X60D5M-I/4FB

The SAM9X60D5M-I/4FB is an ARM926EJ-S microprocessor IC delivering a single 32‑bit core at 600 MHz in a 233‑TFBGA (14×14) package. Designed for embedded and industrial applications, it combines processing performance with integrated interfaces and security features to address control, networking, and user‑interface tasks.

Key Features

• Core — ARM926EJ-S single 32‑bit core running at 600 MHz for deterministic embedded processing.
• Memory — On‑chip memory controllers for LPDDR, LPSDR, DDR2, SDR and SRAM to support a range of external memory architectures.
• Interfaces — Dual 10/100 Mbps Ethernet controllers and three USB 2.0 ports for network and peripheral connectivity.
• Display & HMI — Display interface controllers for keyboard, LCD and touchscreen integration, plus graphics acceleration to support visual user interfaces.
• Security — Comprehensive security features including boot security, cryptography, memory scrambling, Secure JTAG, secure key storage, secure RTC and tamper pins.
• Power & I/O — 3.3 V I/O voltage standard for compatibility with common embedded peripherals.
• Package & Mounting — 233‑TFBGA (14×14) surface‑mount package enabling compact board designs.
• Operating Range — Industrial grade operation from −40 °C to 85 °C for deployment in demanding environments.
• Compliance — RoHS compliant.

Typical Applications

• Industrial Control: Use the 600 MHz ARM926EJ‑S core and industrial temperature rating for embedded controllers and process automation nodes.
• Human‑Machine Interfaces (HMI): LCD, touchscreen and keyboard controllers plus graphics acceleration enable compact operator panels and display systems.
• Networking & Communication: Dual 10/100 Mbps Ethernet and multiple USB 2.0 ports support networked devices, gateways and peripheral connectivity.
• Secure Embedded Systems: Built‑in boot security, cryptography and tamper protection for applications requiring hardware security and secure key storage.

Unique Advantages

• High‑performance embedded processing: A 600 MHz ARM926EJ‑S core provides responsive control and application processing within a single 32‑bit core design.
• Flexible memory support: Multiple memory controller options (LPDDR, LPSDR, DDR2, SDR, SRAM) simplify integration with a variety of memory architectures.
• Integrated connectivity: Dual Ethernet and three USB 2.0 ports reduce external interface requirements and simplify board design for networked products.
• Comprehensive hardware security: Boot security, cryptography, secure JTAG and secure key storage enhance device trust and protect sensitive data.
• Industrial robustness: −40 °C to 85 °C operating range and industrial grade classification support deployment in harsh environments.
• Compact surface‑mount package: 233‑TFBGA (14×14) packaging supports high‑density, space‑constrained designs.

Why Choose SAM9X60D5M-I/4FB?

The SAM9X60D5M-I/4FB positions itself as a versatile, industrial‑grade microprocessor solution that combines a 600 MHz ARM926EJ‑S core with broad interface, memory and security capabilities in a compact 233‑TFBGA package. It is suited to embedded designs that require a balance of processing performance, integrated connectivity and hardware security.

Manufactured by Microchip Technology, this device is tailored for engineering teams building industrial controllers, HMIs, secure gateways and other embedded systems that demand reliable operation across a wide temperature range and flexible memory and interface options.

Request a quote or submit an inquiry to obtain pricing and lead‑time information for SAM9X60D5M-I/4FB and to discuss your design requirements with our team.
