The 10M04SCE144C8G is a MAX® 10 field programmable gate array manufactured by Intel, delivered in a 144-LQFP exposed pad package for surface-mount assembly. It provides a compact, commercial-grade FPGA solution with up to 4,000 logic elements, 193,536 bits of on-chip RAM and 101 user I/O pins for integrating custom digital functions.

Designed for commercial embedded designs, the device operates from a 2.85 V to 3.465 V supply and supports an operating temperature range of 0 °C to 85 °C, making it suitable for a wide range of room-temperature applications that require moderate logic density and on-chip memory.

Key Features

• Core Logic  4,000 logic elements provide programmable fabric for implementing custom digital logic and control functions.
• Logic Array Blocks  250 logic array blocks (LABs) available to structure designs and map combinational and sequential logic.
• On-Chip Memory  193,536 bits of total RAM allow storage for buffers, state machines, and small data structures without external memory.
• I/O Count  101 user I/O pins enable extensive device interfacing for peripherals, sensors, and external logic.
• Power  Supports a supply voltage range of 2.85 V to 3.465 V to match common commercial power rails.
• Package & Mounting  144-LQFP with exposed pad in a 20 × 20 mm footprint (supplier device package: 144-EQFP (20x20)) designed for surface-mount assembly.
• Temperature & Grade  Commercial grade device specified for 0 °C to 85 °C operation.
• Environmental Compliance  RoHS compliant for materials and manufacturing in line with common environmental requirements.

Typical Applications

• Commercial Embedded Systems  Implement custom control, glue logic and peripheral interfacing where a commercial-grade FPGA with up to 4,000 logic elements and 101 I/Os is required.
• Industrial Control (Room-Temperature)  Use in room-temperature industrial equipment that operates within 0 °C to 85 °C and benefits from on-chip RAM and programmable logic.
• Interface and Protocol Bridging  Map protocol conversion or signal aggregation functions using available I/O and on-chip memory to minimize external components.

Unique Advantages

• Balanced Logic and Memory:  4,000 logic elements combined with 193,536 bits of RAM support moderately complex designs without external memory.
• High I/O Density:  101 user I/Os give flexibility to connect multiple peripherals and interfaces directly to the FPGA fabric.
• Commercial-Grade Availability:  Specified for 0 °C to 85 °C operation, making it appropriate for a wide range of commercial electronic products.
• Standard Surface-Mount Package:  144-LQFP exposed pad in a 20 × 20 mm footprint simplifies PCB layout for compact designs and standard assembly processes.
• RoHS Compliant:  Meets common environmental compliance requirements for commercial products.

Why Choose 10M04SCE144C8G?

The 10M04SCE144C8G delivers a focused mix of programmable logic, substantial on-chip RAM, and a high I/O count in a commercial-grade, surface-mount 144-LQFP package. It is well suited to developers and procurement teams building commercial embedded systems that require moderate logic density, integrated memory, and a compact board footprint.

Its balanced specification set—4,000 logic elements, 193,536 bits of RAM, 101 I/Os, and a 2.85 V to 3.465 V supply range—provides a reliable platform for scalable, maintainable designs supported by Intel's MAX® 10 product family.
