5AGXMA1D6F27C6N

The 5AGXMA1D6F27C6N is an Arria V GX field programmable gate array (FPGA) in a 672-ball BGA (FCBGA) package designed for commercial-grade applications. It integrates 75,000 logic elements, approximately 8.66 Mbits of embedded RAM, and 336 user I/Os to support complex, reconfigurable digital designs.

Designed for surface-mount assembly, the device operates from a core supply of 1.07 V to 1.13 V and is rated for a commercial temperature range of 0 °C to 85 °C. The package is supplied as a 672-FBGA (27×27) footprint for high-density board-level integration.

Key Features

• Core Logic Capacity  75,000 logic elements provide substantial programmable fabric for custom digital functions and complex finite-state machines.
• Logic Structure  3,537 logic blocks (as specified) for organized resource distribution within the programmable fabric.
• Embedded Memory  Approximately 8.66 Mbits of on-chip RAM to support buffering, packet storage, and localized data structures without external memory.
• I/O Count  336 general-purpose I/Os for high pin-count interfacing and flexible peripheral connections.
• Package & Mounting  672-BBGA FCBGA package (672-FBGA, 27×27) in a surface-mount form factor for dense PCB layouts.
• Power Supply  Core operating voltage range: 1.07 V to 1.13 V, enabling predictable core power provisioning.
• Operating Grade and Temperature  Commercial grade with an operating range of 0 °C to 85 °C for standard commercial environments.
• Environmental Compliance  RoHS compliant.

Typical Applications

• Custom digital logic and prototyping  Reconfigurable platform for implementing application-specific digital functions and accelerating development cycles.
• High-density I/O control  Leverages 336 I/Os for board-level interfacing, parallel bus management, and multi-channel signal routing.
• Embedded memory buffering  On-chip RAM supports buffering and local data storage to reduce dependence on external memory devices.

Unique Advantages

• Substantial programmable capacity:  75,000 logic elements give designers the headroom to implement complex datapaths and control logic within a single device.
• Generous on-chip memory:  Approximately 8.66 Mbits of embedded RAM minimizes external memory requirements for many use cases.
• High I/O density:  336 I/Os enable versatile connectivity for multi-channel systems or extensive peripheral interfaces.
• Industry-standard packaging:  672-BBGA (27×27) FCBGA package simplifies high-density board integration and assembly processes.
• Commercial temperature rating:  Rated 0 °C to 85 °C to match typical commercial electronics deployment environments.
• Regulatory friendliness:  RoHS compliance supports environmentally conscious product designs.

Why Choose 5AGXMA1D6F27C6N?

The 5AGXMA1D6F27C6N Arria V GX FPGA delivers a balanced combination of logic density, embedded memory, and I/O availability in a compact 672-BBGA surface-mount package. Its commercial-grade profile and defined core voltage range make it suitable for teams building high-capacity, reconfigurable digital systems that require on-chip RAM and extensive I/O without expanding board area.

Choose this device when your design requires a single, integrated FPGA solution that provides sizable programmable resources, predictable supply requirements, and a package tailored for dense PCB layouts.

Request a quote or submit an RFQ to receive pricing and availability information for the 5AGXMA1D6F27C6N Arria V GX FPGA.
