APA1000-FG1152

The APA1000-FG1152 is a ProASICPLUS Field Programmable Gate Array from Microchip Technology. It provides 56,320 logic elements, approximately 0.20 Mbits of embedded memory (202,752 bits) and roughly 1,000,000 gates in a high-density 1152-FPBGA (35×35) package.

Designed for commercial-grade applications, the device supports up to 712 I/Os and operates from a 2.3 V to 2.7 V supply with an operating temperature range of 0 °C to 70 °C. The package is surface-mount and RoHS compliant.

Key Features

• Logic Capacity  56,320 logic elements provide substantial programmable logic resources for mid-to-high complexity designs.
• Embedded Memory  Approximately 0.20 Mbits (202,752 bits) of on-chip RAM to support buffering, FIFOs, and local storage for logic functions.
• I/O Density  Up to 712 I/O pins enable broad peripheral connectivity and complex signal routing in a single device.
• Gate Count  Approximately 1,000,000 gates for implementing sizeable custom logic and control functions.
• Power and Voltage  Operates from a 2.3 V to 2.7 V supply, suitable for systems designed around that voltage range.
• Package and Mounting  1152-FPBGA (35×35) package, surface-mount mounting type, offering high I/O in a compact footprint.
• Commercial Temperature Grade  Rated for 0 °C to 70 °C operation for commercial-environment deployments.
• Environmental Compliance  RoHS compliant to support regulatory and manufacturing requirements.

Typical Applications

• High-density I/O Systems  Leverage the 712 I/Os for complex sensor arrays, multi-channel interfacing, or board-level consolidation of peripherals.
• Custom Logic and Control  Use the 56,320 logic elements and ~1,000,000 gates to implement state machines, protocol handling, and control logic.
• On-chip Data Buffering  Utilize approximately 0.20 Mbits of embedded memory for temporary storage, FIFO buffering, and small data caches within logic designs.

Unique Advantages

• High Logic Density: 56,320 logic elements enable implementation of complex functions without immediate need for multiple devices, reducing board-level integration.
• Extensive I/O Count: 712 I/Os provide flexibility to connect many peripherals or signals directly to the FPGA, simplifying system architecture.
• Compact BGA Package: The 1152-FPBGA (35×35) package balances high pin count with a compact footprint suitable for space-conscious boards.
• Commercial-grade Operation: Rated for 0 °C to 70 °C, matching typical commercial product requirements and development environments.
• Regulatory Compliance: RoHS compliance supports environmentally conscious manufacturing and supply chain requirements.

Why Choose APA1000-FG1152?

The APA1000-FG1152 combines substantial programmable logic resources with a high I/O count and embedded memory in a compact 1152-FPBGA package, offering a balanced solution for mid-complexity commercial designs. Its voltage range, commercial temperature rating, and RoHS compliance make it practical for a wide array of development and production environments where these specifications are required.

This device is suited for engineers and teams seeking a Microchip ProASICPLUS FPGA with significant logic capacity, dense connectivity, and on-chip memory—delivering integration and flexibility for custom logic, control systems, and I/O-heavy designs.

Request a quote or submit an inquiry to receive pricing and availability for the APA1000-FG1152. Our team can assist with lead times and ordering information.
