XC5VFX100T-1FF1738C

The XC5VFX100T-1FF1738C is a Virtex®-5 FXT field programmable gate array (FPGA) in a 1738-ball FCBGA package. It provides high logic capacity and on-chip memory along with a large I/O count for complex, highly integrated digital designs.

Targeted at commercial applications, this device combines 102,400 logic elements, approximately 8.4 Mbits of embedded memory, and 680 I/O to support designs that require significant logic, memory, and connectivity within a single surface-mount package.

Key Features

• Logic Capacity — 102,400 logic elements and 8,000 configurable logic blocks (CLBs) to implement large-scale digital logic and custom processing functions.
• Embedded Memory — Approximately 8.4 Mbits of on-chip RAM to store buffers, lookup tables, and intermediate data without external memory.
• I/O Resources — 680 user I/O pins to support dense connectivity and multiple parallel interfaces.
• Power Supply — Core supply range from 950 mV to 1.05 V, enabling defined core power design and planning.
• Package — 1738-ball FCBGA (1738-BBGA) package, supplier device package specified as 1738-FCBGA (42.5×42.5 mm) for high-density board integration.
• Mounting and Grade — Surface mount device with commercial grade rating and operating temperature range of 0 °C to 85 °C.
• Environmental Compliance — RoHS compliant.

Typical Applications

• Complex digital systems — Designs that require large logic counts and substantial embedded memory to implement custom processing and control functions.
• High-density I/O implementations — Systems needing many external interfaces or parallel connections, leveraging the device's 680 user I/O pins.
• Integrated single-package solutions — Applications that benefit from combining logic, memory, and I/O in a single FCBGA package for board space optimization.

Unique Advantages

• High logic density: 102,400 logic elements provide capacity for large designs and complex combinational and sequential logic implementations.
• Substantial on-chip memory: Approximately 8.4 Mbits of embedded RAM reduces reliance on external memory components and simplifies board design.
• Extensive I/O: 680 I/O pins support multiple interfaces and high pin-count requirements without additional multiplexing hardware.
• Compact, manufacturable package: The 1738-FCBGA (42.5×42.5 mm) surface-mount package supports high-density PCB layouts and automated assembly processes.
• Commercial temperature rating: Specified 0 °C to 85 °C operating range for standard commercial deployments.
• RoHS compliant: Meets common environmental compliance requirements for modern electronic products.

Why Choose XC5VFX100T-1FF1738C?

The XC5VFX100T-1FF1738C positions itself as a high-capacity, highly integrated FPGA option for commercial designs that need large logic resources, significant on-chip memory, and extensive I/O within a single FCBGA package. Its specified supply and operating temperature ranges make it suitable for standard commercial environments.

Designers and procurement teams building complex digital systems, multi-interface platforms, or space-constrained boards will find the device’s combination of logic elements, embedded RAM, and 680 I/O pins beneficial for reducing component count and simplifying system architecture.

Request a quote or submit an inquiry to obtain pricing, availability, and lead-time information for the XC5VFX100T-1FF1738C.
