XC5VLX30-3FFG324C
| Part Description |
Virtex®-5 LX Field Programmable Gate Array (FPGA) IC 220 1179648 30720 324-BBGA, FCBGA |
|---|---|
| Quantity | 1,006 Available (as of October 8, 2026) |
| Product Category | Field Programmable Gate Array (FPGA) |
|---|---|
| Manufacturer | AMD |
| Manufacturing Status | Active |
| Manufacturer Standard Lead Time | 12 Weeks |
| Datasheet |
Specifications & Environmental
| Device Package | 324-FCBGA (19x19) | Grade | Commercial | Operating Temperature | 0°C – 85°C | ||
|---|---|---|---|---|---|---|---|
| Package / Case | 324-BBGA, FCBGA | Number of I/O | 220 | Voltage | 950 mV - 1.05 V | ||
| Mounting Method | Surface Mount | RoHS Compliance | ROHS3 Compliant | REACH Compliance | REACH Unaffected | ||
| Moisture Sensitivity Level | 4 (72 Hours) | Number of LABs/CLBs | 2400 | Number of Logic Elements/Cells | 30720 | ||
| Number of Gates | N/A | ECCN | 3A991D | HTS Code | 8542.39.0001 | ||
| Qualification | N/A | Total RAM Bits | 1179648 |
Overview of XC5VLX30-3FFG324C – Virtex®-5 LX FPGA, 30,720 logic elements, 324-FCBGA
The XC5VLX30-3FFG324C is a commercial-grade Virtex®-5 LX field programmable gate array (FPGA) offered in a 324-ball FCBGA package. It delivers a combination of high logic capacity, substantial on-chip memory, and broad I/O connectivity for commercial reconfigurable designs.
With 30,720 logic elements, approximately 1.18 Mbits of embedded RAM, and up to 220 I/O, this device is suited for commercial applications that require dense logic implementation and flexible interfacing in a compact surface-mount form factor.
Key Features
- Core Logic 30,720 logic elements provide significant configurable logic capacity for complex custom functions and data-path implementations.
- Configurable Logic Blocks (CLBs) Approximately 2,400 CLBs for structured logic partitioning and modular design.
- Embedded Memory Approximately 1.18 Mbits of on-chip RAM supports buffering, FIFOs, and distributed memory needs without external devices.
- I/O Density Up to 220 I/O pins enable broad peripheral connectivity and high-pin-count system integration.
- Power Core supply operation specified between 0.95 V and 1.05 V to match system power-rail planning and low-voltage designs.
- Package & Mounting 324-ball FCBGA (324-BBGA) package, supplier package 324-FCBGA (19×19), optimized for surface-mount PCB assembly and compact board layouts.
- Operating Range Commercial operating temperature range from 0 °C to 85 °C for typical commercial-environment deployments.
- Regulatory RoHS compliant for environmental and regulatory conformity in commercial products.
Typical Applications
- Commercial communications equipment Implement protocol processing, packet handling, and custom bridging functions using the device’s logic density and on-chip RAM.
- High-density I/O subsystems Drive multi-interface boards and custom peripheral clusters with up to 220 general-purpose I/O pins.
- Embedded system prototyping Rapidly iterate hardware algorithms and custom accelerators leveraging a large pool of logic elements and memory resources.
- Custom hardware acceleration Offload compute-intensive tasks to reconfigurable logic to tailor performance and functionality for commercial applications.
Unique Advantages
- High logic capacity: 30,720 logic elements allow implementation of complex, multi-function designs on a single device, reducing board-level complexity.
- Substantial embedded memory: Approximately 1.18 Mbits of on-chip RAM minimizes the need for external memory in many buffering and state-storage use cases.
- Wide I/O complement: Up to 220 I/O pins provide flexibility for interfacing to a variety of peripherals and external devices.
- Compact packaging: 324-FCBGA (19×19) package enables high-density mounting and compact PCB layouts while preserving routing capability.
- Commercial-grade readiness: Specified 0 °C to 85 °C operation and RoHS compliance make it appropriate for mainstream commercial deployments.
- Low-voltage core: Core supply range of 0.95 V to 1.05 V supports low-voltage system architectures and power budgeting.
Why Choose XC5VLX30-3FFG324C?
The XC5VLX30-3FFG324C positions itself as a capable commercial FPGA option where substantial logic density, embedded memory, and flexible I/O are required in a compact surface-mount package. Its combination of 30,720 logic elements, approximately 1.18 Mbits of RAM, and 220 I/O pins provides designers with the resources to consolidate functions and reduce external component count.
Choose this device for commercial designs that need scalable logic resources, substantial on-chip storage, and a 324-FCBGA footprint for space-constrained PCBs. The part’s electrical and mechanical specifications support reliable integration into mainstream commercial products.
Request a quote or submit a purchase inquiry today to evaluate how XC5VLX30-3FFG324C fits your next commercial FPGA design.
