MC9328MXLCVM15R2

The MC9328MXLCVM15R2 is an ARM920T-based 32-bit microprocessor in the MC9328 (i.MXL) family, featuring a single core running at 150 MHz and a highly integrated peripheral set. It targets embedded and portable applications that require display support, removable storage interfaces, and robust I/O integration.

Designed for industrial use, the device combines an ARM920T core with on-chip controllers and power management features to simplify system design and support operation across a wide temperature range.

Key Features

• Core — ARM920T 32-bit microprocessor core, single core operating at 150 MHz.
• Memory and Bus — Integrated SDRAM controller and AHB-to-IP bus interfaces for standard external memory and peripheral interconnects.
• Display and Multimedia — On-chip LCD controller and multimedia-related modules to support display-driven portable products.
• Storage and USB — MMC/SD host controller and Memory Stick® host controller plus a USB device interface (USB 1.x) for removable media and host connectivity.
• Serial and Peripheral Interfaces — I2C, SPI, UARTs, SSI/I2S and GPIO provide flexible connectivity for sensors, displays and user I/O.
• Timers and System Control — Watchdog timer, real-time clock, two general-purpose 32-bit timers, PWM and a direct memory access controller (DMAC) for deterministic control and background transfers.
• Power and Clock — DPLL clock and power control module along with power management features; documented core voltage range and I/O voltage support in the series datasheet.
• Package and Mounting — 256-PBGA (14×14) / 256-LFBGA surface-mount package for compact system integration.
• Qualification and Temperature — Industrial qualification with an operating temperature range of −40 °C to 85 °C.
• Regulatory — RoHS compliant.

Typical Applications

• Portable multimedia devices — Integrated LCD controller, MMC/SD and Memory Stick host support user displays and removable media in compact handheld products.
• Embedded industrial systems — Industrial qualification and −40 °C to 85 °C operating range make the device suitable for control and monitoring applications in demanding environments.
• Human-machine interfaces (HMI) — LCD controller, GPIO and serial peripherals enable display-driven operator panels and user interface modules.

Unique Advantages

• Highly integrated peripheral set: On-chip LCD, storage hosts, USB device and serial interfaces reduce external components and simplify board design.
• Deterministic embedded performance: ARM920T single-core operation at 150 MHz provides a focused processing foundation for control and multimedia tasks.
• Industrial-grade thermal range: Rated for −40 °C to 85 °C to support deployments in harsh temperature conditions.
• Compact surface-mount package: 256-PBGA (14×14) package enables dense, space-conscious layouts.
• On-chip system control and power management: DPLL clocking and power control features help manage power and clock resources for efficient operation.
• Standards-aligned I/O: Multiple serial interfaces (I2C, SPI, UART, SSI/I2S) and GPIO provide broad connectivity for sensors, displays and peripherals.

Why Choose MC9328MXLCVM15R2?

The MC9328MXLCVM15R2 positions the MC9328 (i.MXL) family’s ARM920T architecture in a compact, industrially qualified package with a balanced mix of processing, display and storage interfaces. It is suited to embedded and portable designs that need on-chip controllers to minimize external components while maintaining predictable 32-bit processing performance.

Backed by NXP Semiconductors’ MC9328 series documentation, this part is appropriate for developers seeking a single-core ARM920T solution with integrated peripherals, power management capabilities and long-term availability considerations for production designs.

Request a quote or submit an inquiry to check pricing and availability for the MC9328MXLCVM15R2. Our team can provide configuration and ordering information to support your design cycle.
