MC9328MXLDVM15R2

The MC9328MXLDVM15R2 is a single-core, 32-bit microprocessor built around the ARM920T core running at 150 MHz. Designed for personal and portable embedded applications, it combines a processor core with integrated system functions and peripheral controllers to support multimedia, display, storage and general embedded control tasks.

With on-chip interfaces and controllers, this i.MXL-series device targets compact, feature-rich designs requiring a balance of performance, integration and power management in a 256-ball PBGA surface-mount package.

Key Features

• Core  ARM920T single 32-bit core operating at 150 MHz, providing deterministic processing for embedded applications.
• Memory and Bus  Integrated SDRAM controller plus AHB-to-IP bus interfaces and external interface support to simplify memory subsystem design.
• Display and Multimedia  On-chip LCD controller and multimedia accelerator/video port support display and multimedia functionality for portable devices.
• Connectivity and Peripherals  Includes USB device support (USB 1.x), I2C, SPI, UARTs, MMC/SD host controller and Memory Stick® host controller for flexible I/O and storage options.
• Audio and Serial  SSI/I2S and serial peripheral interfaces for audio and synchronous serial data paths.
• Timers and System Control  Multiple timers, PWM, watchdog timer and real-time clock for robust system timing and control.
• DMA and GPIO  Direct Memory Access Controller (DMAC) and general-purpose I/O for efficient data movement and board-level control.
• Power and Clock Management  Integrated DPLL clock and power control module with power management features to help optimize energy use.
• Package and Mounting  256‑PBGA (14×14) surface-mount package (256-LFBGA listed as package case); compact BGA footprint for space-constrained designs.
• Operating Range  Specified operating temperature range of −30 °C to 70 °C for deployments in a wide range of ambient conditions.
• Compliance  RoHS compliant.

Typical Applications

• Portable multimedia devices  Integrated LCD controller and multimedia features enable user interfaces and media playback in handheld products.
• Handheld and consumer electronics  Compact PBGA packaging and integrated peripherals support space-constrained consumer designs.
• Embedded control with storage  MMC/SD and Memory Stick host controllers plus SDRAM interface make it suitable for embedded systems requiring local removable storage.

Unique Advantages

• Highly integrated peripherals: On-chip USB device, LCD controller, MMC/SD and multiple serial interfaces reduce external component count and simplify PCB design.
• Balanced performance and efficiency: ARM920T core at 150 MHz provides a practical mix of compute capability and power-conscious operation for portable applications.
• Flexible memory support: Built-in SDRAM controller and external interface options facilitate a range of memory configurations and system architectures.
• Compact BGA packaging: 256-PBGA (14×14) surface-mount package enables dense board layouts and small form-factor products.
• System reliability features: Watchdog, real-time clock and DMA support robust, deterministic embedded operation.
• RoHS compliant: Meets environmental compliance requirements for modern electronics manufacturing.

Why Choose MC9328MXLDVM15R2?

The MC9328MXLDVM15R2 positions itself as a compact, integrated microprocessor solution for designers of portable and embedded multimedia devices. Its ARM920T core, combined with on-chip display, storage and serial interfaces, lets teams deliver feature-rich products while reducing external component count.

Ideal for projects where board space, peripheral integration and documented vendor support matter, this device offers a clear, verifiable specification set—including a 150 MHz core, SDRAM controller, multiple peripheral controllers and a 256‑PBGA package—backed by datasheet documentation from the manufacturer.
