MC9328MXLDVM20

The MC9328MXLDVM20 is an i.MXL family microprocessor from NXP Semiconductors based on the ARM920T core. It delivers a single 32‑bit core running at up to 200 MHz with integrated system functions tailored for embedded and portable multimedia applications.

Designed for compact, power‑managed designs, the device combines a high‑efficiency ARM9 core with on‑chip peripherals such as an LCD controller, USB device, MMC/SD host controller and SDRAM interface to simplify board-level integration and accelerate product development.

Key Features

• Processor Core and Performance — ARM920T single 32‑bit core operating at up to 200 MHz, providing deterministic processing for embedded workloads.
• Memory and External Interface — Integrated SDRAM controller and External Interface Module (EIM) to support external memory and high‑bandwidth system configurations.
• Display and Multimedia — On‑chip LCD controller and Video Port for embedded display and multimedia applications.
• Storage and Host Interfaces — MMC/SD host controller and Memory Stick® host controller for removable media support and local storage options.
• Connectivity and Serial Peripherals — USB device, I2C bus module, Serial Peripheral Interface (SPI), UARTs and SSI/I2S for broad peripheral connectivity.
• System Timing and Control — Two general‑purpose 32‑bit counters/timers, PWM module, real‑time clock (RTC) and watchdog timer for robust system control.
• DMA and Acceleration — Direct Memory Access Controller (DMAC) and Multimedia Accelerator (MMA) to offload data movement and media processing tasks.
• Clock and Power Management — DPLL clock and power control module and power management features; operating voltage range cited in documentation: core 1.7 V to 1.9 V and I/O 1.7 V to 3.3 V.
• Package and Mounting — 256‑contact PBGA package (14 × 14 mm), surface‑mount mounting for compact board layouts.
• Operating Range and Compliance — Rated for operation from −30 °C to 70 °C and RoHS compliant.

Typical Applications

• Portable Multimedia Devices — Integrated LCD controller, video port and multimedia acceleration enable compact, display‑centric handheld designs.
• Handheld and Pocket Computing — ARM920T performance with SDRAM support makes the device suitable for handheld user interfaces and control logic.
• Embedded Display and HMI Controllers — On‑chip display and serial interfaces simplify human‑machine interface implementations.
• Removable Media and USB Peripherals — MMC/SD and Memory Stick host controllers plus USB device support storage and accessory connectivity.

Unique Advantages

• Highly integrated peripheral set: On‑chip LCD controller, USB device, MMC/SD and Memory Stick host controllers reduce bill of materials and board complexity.
• Balanced processing and power: ARM920T single core at 200 MHz provides embedded processing capability while enabling power management through integrated clock and power control.
• Flexible memory support: SDRAM controller and External Interface Module allow designers to tailor memory architectures for performance or cost.
• Comprehensive I/O connectivity: Multiple serial interfaces (I2C, SPI, UART, SSI/I2S) simplify sensor, display and peripheral integration.
• Compact, manufacturable package: 256‑PBGA (14×14 mm) surface‑mount package supports dense PCB layouts and automated assembly.
• Industrial temperature coverage and compliance: −30 °C to 70 °C operating range and RoHS compliance support regulated manufacturing and deployment.

Why Choose MC9328MXLDVM20?

The MC9328MXLDVM20 combines a proven ARM920T core with an extensive set of integrated peripherals to deliver a practical platform for embedded and portable multimedia designs. Its combination of display, storage and serial connectivity options reduces system complexity and accelerates time to market.

Engineers and procurement teams seeking a compact, RoHS‑compliant microprocessor with on‑chip memory controllers, multimedia interfaces and power management features will find the MC9328MXLDVM20 well suited to products that require a balanced mix of processing capability and integration.

Request a quote or submit an inquiry to receive pricing and availability for the MC9328MXLDVM20 and to discuss how this device fits your next embedded design.
