MC9328MXLDVM15

The MC9328MXLDVM15 is an ARM920T-based 32-bit microprocessor running at 150 MHz, designed for embedded and portable multimedia applications. It combines a single ARM920T core with integrated memory controllers and a broad set of on-chip peripherals to simplify system design and accelerate time-to-market.

Targeted at personal and portable product markets, the device delivers integrated display, storage and connectivity interfaces along with power management features and a compact 256-PBGA (14×14) surface-mount package.

Key Features

• Core ARM920T 32-bit microprocessor core providing deterministic embedded processing in a single-core configuration.
• Performance 150 MHz operating frequency for control and multimedia tasks in compact embedded systems.
• Memory and Bus Integrated SDRAM controller and AHB-to-IP bus interfaces to support external memory and efficient data movement.
• Peripherals and Timers On-chip peripherals including two UARTs, SPI, PWM module, multiple 32-bit timers, watchdog timer and real-time clock for robust system control.
• Display and Multimedia Integrated LCD controller and video port plus multimedia accelerator functionality to support rich user interfaces and graphics-driven displays.
• Connectivity and Storage USB device, MMC/SD host controller and Memory Stick host controller provide flexible connectivity and removable storage options; additional interfaces include I2C and SSI/I²S.
• System and Power Management DPLL clock and power control module and power management features enable optimized clocking and low-voltage operation (documented core and I/O voltage ranges in the product family datasheet).
• Package and Environmental 256-PBGA (14×14) surface-mount package; RoHS compliant; rated for operation from −30 °C to +70 °C.

Typical Applications

• Portable multimedia devices — Integrated LCD controller, removable-storage host controllers and USB device support media playback, storage and user interaction in compact products.
• Handheld and mobile terminals — UARTs, timers, I2C and SPI enable reliable sensor, radio and peripheral interfacing for mobile data-capture devices.
• Embedded human–machine interfaces (HMIs) — LCD controller, GPIO and multimedia features support rich, interactive displays for control panels and user interfaces.
• Peripheral devices and accessories — USB device and multimedia host interfaces make the part suitable for accessories requiring removable storage and host connectivity.

Unique Advantages

• Highly integrated peripheral set: On-chip SDRAM controller, LCD controller, USB device, MMC/SD and Memory Stick host controllers reduce external component count and simplify BOM.
• Compact surface-mount package: 256-PBGA (14×14) enables dense board layouts for space-constrained designs.
• Designed for portable product markets: Integration of multimedia, display and storage interfaces aligns with requirements for personal and portable devices described in the product family documentation.
• Flexible power and clock control: DPLL clocking and power management modules support tailored power/clock strategies for energy-conscious designs.
• Robust system features: DMA controller, watchdog, RTC and multiple timers help manage data movement and system reliability without extensive external logic.
• Regulatory readiness: RoHS compliant for lead-free assembly requirements.

Why Choose MC9328MXLDVM15?

The MC9328MXLDVM15 pairs an ARM920T 150 MHz core with a comprehensive set of integrated peripherals and memory controllers to address embedded multimedia and portable system designs. Its combination of display, storage and connectivity interfaces reduces external components and simplifies hardware design.

Engineers building LCD-based interfaces, removable-storage-enabled devices or compact consumer and industrial embedded systems will find a documented hardware foundation and on-chip features that support development and production needs. The device is supplied by NXP Semiconductors and is supported by detailed product documentation.

Request a quote or submit an inquiry today to receive pricing, lead-time and availability information for the MC9328MXLDVM15.
