MPC8265ACZUMIBC

The MPC8265ACZUMIBC is a single‑core PowerPC G2 microprocessor in the MPC82xx family, running at 266 MHz and packaged in a 480‑TBGA (37.5 × 37.5 mm) surface‑mount package. It targets embedded and communications‑focused industrial applications that require integrated networking, on‑chip co‑processing and rugged temperature capability.

Built for embedded communications and industrial control designs, this device combines a 32‑bit G2 core with communications co‑processor resources, memory controllers and multiple 10/100 Mbps Ethernet interfaces, while meeting industrial qualification and RoHS compliance.

Key Features

• Core One PowerPC G2 32‑bit core operating at 266 MHz, with on‑chip memory management support as described for the MPC826xA family.
• Cache and MMU Separate instruction and data caches and a PowerPC‑architecture MMU are included in the MPC826xA series hardware specifications.
• Communications Co‑processor Integrated communications co‑processor (RISC CPM) and communications resources drawn from the MPC826xA family design to support protocol and data‑path tasks.
• Ethernet Multiple 10/100 Mbps Ethernet interfaces (specified as 10/100 Mbps (3) in device specifications) for networked and industrial Ethernet applications.
• Memory Controllers On‑chip controllers for DRAM and SDRAM to support system memory requirements.
• Interfaces I2C listed among additional interfaces; the MPC826xA series documentation describes a comprehensive set of serial/peripheral interfaces for embedded systems.
• Clocking and Power I/O operates at 3.3 V; the MPC826xA family includes separate power domains and PLL/clock multiplier options enabling independent core and communications processor frequencies for power/performance tuning.
• Package and Mounting 480‑TBGA (37.5 × 37.5 mm) package, 480‑LBGA with exposed pad, surface‑mount mounting for PCB integration.
• Industrial Qualification and Temperature Range Qualified for industrial use with an operating temperature range of −40 °C to 105 °C and RoHS compliance.

Typical Applications

• Embedded Communications Use the on‑chip communications resources and multiple 10/100 Mbps Ethernet ports for networked protocol processing and data routing in embedded systems.
• Industrial Networking Industrial controllers and gateways benefit from the industrial qualification and wide operating temperature range for reliable field deployment.
• Control and Automation Leverage the PowerPC G2 core and DRAM/SDRAM controllers for real‑time control tasks and local data buffering in automation equipment.
• Telecommunications Equipment The integrated communications co‑processor and serial/peripheral interfaces suit management and data‑plane tasks in communications hardware.

Unique Advantages

• Integrated Communications Engine: On‑chip communications co‑processor (CPM) reduces external logic and simplifies protocol offload for embedded networking designs.
• Flexible Clocking and Power Domains: Separate PLLs and clock multipliers for the G2 core and CPM allow designers to balance performance and power across subsystems.
• Network‑Ready Connectivity: Multiple 10/100 Mbps Ethernet interfaces provide native network connectivity for gateway and communication‑centric applications.
• Industrial Reliability: Industrial qualification and an operating range of −40 °C to 105 °C support deployment in harsh or outdoor environments.
• System Memory Support: Built‑in DRAM and SDRAM controllers simplify memory subsystem design and reduce external component count.
• RoHS Compliant Packaging: Lead‑free, surface‑mount 480‑TBGA package suitable for modern, environmentally compliant production processes.

Why Choose MPC8265ACZUMIBC?

The MPC8265ACZUMIBC positions itself as a purpose‑built embedded communications processor that combines a PowerPC G2 core, integrated communications co‑processing, and native Ethernet connectivity in a single industrial‑qualified device. Its package and thermal ratings make it suitable for rugged embedded and networking applications that require sustained operation across a wide temperature range.

Designers and procurement teams looking for a field‑proven MPC82xx family device will find the MPC8265ACZUMIBC offers a balance of compute, communications integration and system‑level interfaces backed by established MPC826xA family documentation from the manufacturer.

Request a quote or submit an inquiry for pricing, availability and volume options to evaluate the MPC8265ACZUMIBC for your next embedded communications or industrial networking design.
