OMAPL138AZWTA3

The OMAPL138AZWTA3 from Texas Instruments is a microprocessor IC in the OMAP-L13x series that combines an ARM926EJ-S application core with a dedicated C674x signal-processing coprocessor. Designed for embedded applications, the device integrates a range of interfaces and security features to support systems that require processing and I/O consolidation.

This single-core, 32-bit processor package is supplied in a 361-ball BGA and is RoHS compliant, making it suitable for surface-mount assembly in embedded product designs.

Key Features

• Core and Coprocessors The device uses an ARM926EJ-S core (single 32-bit core) and includes coprocessors for signal processing (C674x) and system control (CP15) to offload specialized tasks.
• Display Interface Includes an LCD display interface controller to support local visual output and user interfaces.
• Network and Storage Interfaces Integrated 10/100Mbps Ethernet and a SATA 3Gbps interface provide wired networking and storage connectivity options.
• USB Connectivity Provides both USB 1.1 + PHY and USB 2.0 + PHY interfaces for external device and host connectivity.
• Security Features Built-in boot security and cryptography functions support secure device boot and data protection workflows.
• Packaging and Mounting Supplied in a 361-LFBGA / 361-NFBGA (16×16) package for surface-mount applications, facilitating compact board-level integration.
• Regulatory Compliance RoHS compliant to meet lead-free assembly requirements.
• Graphics Acceleration No dedicated graphics acceleration is provided, focusing the device on processing and I/O integration.

Typical Applications

• Embedded signal processing Use the ARM926EJ-S core together with the C674x coprocessor to implement DSP-heavy algorithms in compact embedded systems.
• Human–machine interfaces The on-chip LCD controller supports devices that require local display capability for status, controls, or operator feedback.
• Networked systems Integrated 10/100Mbps Ethernet and SATA 3Gbps enable networking and local storage functions in communications or data-logging equipment.
• Peripheral-rich devices Dual USB PHYs (USB 1.1 and USB 2.0) allow flexible connection to external peripherals and hosts in embedded products.

Unique Advantages

• Combined application and DSP processing: The ARM926EJ-S core plus C674x signal-processing coprocessor lets designers partition control and compute tasks across dedicated processors.
• Comprehensive I/O integration: Ethernet, SATA and dual USB PHYs reduce the need for external controllers and simplify board-level design.
• Security-ready boot and cryptography: Built-in boot security and cryptographic features support secure startup and data protection without additional components.
• Surface-mount BGA packaging: The 361-LFBGA / 361-NFBGA (16×16) package enables high-density PCB layouts for space-constrained embedded designs.
• Series continuity: As part of the OMAP-L13x series from Texas Instruments, the component aligns with a consistent family approach for embedded system designs.

Why Choose OMAPL138AZWTA3?

OMAPL138AZWTA3 positions itself as a compact, interface-rich microprocessor IC that pairs an ARM926EJ-S application core with a C674x signal-processing coprocessor, suitable for embedded designs that need both control and DSP capability. Its integrated Ethernet, SATA, USB, LCD controller and onboard security functions help reduce overall system component count.

Engineers and procurement teams looking for a single-package solution for embedded signal processing, networking, and secure boot scenarios will find the OMAPL138AZWTA3 a practical choice for projects requiring consolidated I/O, surface-mount BGA packaging, and RoHS compliance.

Request a quote or submit a purchase inquiry to receive pricing and availability information for the OMAPL138AZWTA3.
