5AGXBA1D6F27C6N

The 5AGXBA1D6F27C6N is an Arria V GX Field Programmable Gate Array (FPGA) in a 672-ball BGA package. Key on-chip resources include 75,000 logic elements, 8,666,112 total RAM bits, and 336 I/O pins, providing a high-density, programmable fabric for complex logic and embedded-memory functions.

This device is supplied as a surface-mount, commercial-grade component with a core voltage supply range of 1.07 V to 1.13 V and an operating temperature range of 0 °C to 85 °C. It is RoHS compliant and is supported by the Arria V device datasheet, which contains detailed electrical, switching, configuration, and I/O timing specifications.

Key Features

• Core Capacity — 75,000 logic elements for implementing complex combinational and sequential logic.
• Embedded Memory — 8,666,112 total RAM bits to support on-chip buffering, FIFOs, and state storage.
• I/O Density — 336 available I/O pins to accommodate parallel interfaces, peripherals, and system-level connections.
• Package & Mounting — 672-BBGA (672-FBGA, 27×27) surface-mount package for compact board-level integration.
• Power — Core voltage supply specified from 1.07 V to 1.13 V for controlled core operation.
• Temperature & Grade — Commercial grade with an operating range of 0 °C to 85 °C for standard embedded applications.
• Environmental Compliance — RoHS compliant.
• Documentation — Supported by the Arria V device datasheet covering electrical characteristics, configuration timing, and I/O timing details.

Typical Applications

• High-density programmable logic — Implement complex custom logic and state machines using the 75,000 logic elements and abundant embedded RAM.
• I/O-rich interface hubs — Use the 336 I/O pins to bridge multiple peripherals, parallel buses, or board-level interfaces.
• Compact board-level systems — The 672-BBGA surface-mount package supports space-constrained PCB designs that require significant on-chip resources.

Unique Advantages

• Significant on-chip resources — A combination of 75,000 logic elements and over 8.6 million RAM bits reduces the need for external memory and discrete logic.
• High I/O count — 336 I/O pins enable flexible system interfacing without sacrificing logic capacity.
• Compact BGA footprint — 672-ball FCBGA (27×27) package provides a dense, board-friendly form factor for embedded systems.
• Commercial operating range — 0 °C to 85 °C specification aligns with standard commercial embedded deployments.
• RoHS compliant — Meets common environmental regulatory requirements for lead-free assemblies.

Why Choose 5AGXBA1D6F27C6N?

The 5AGXBA1D6F27C6N delivers a balanced combination of high logic capacity, large embedded memory, and substantial I/O in a compact BGA package, making it suitable for designs that demand substantial on-chip resources within standard commercial operating conditions. Its defined core voltage range and comprehensive datasheet support provide the electrical and configuration detail engineers rely on for system integration and validation.

Choose this Arria V GX FPGA when your design requires dense programmable logic, extensive on-chip memory, and a high pin count in a manufacturable surface-mount package with RoHS compliance.

Request a quote or submit an inquiry for pricing and availability of the 5AGXBA1D6F27C6N.
