5AGXMA7D4F27C5N

The 5AGXMA7D4F27C5N is an Arria V GX Field Programmable Gate Array (FPGA) IC in a 672-BBGA (27 × 27) FCBGA package designed for commercial-grade applications. It integrates a large programmable fabric with extensive on-chip memory and I/O resources for complex digital designs.

This device provides 242,000 logic elements and approximately 15.47 Mbits of embedded RAM, paired with 336 user I/Os. Detailed electrical characteristics, switching behavior, configuration timing, and I/O timing are documented in the Arria V device datasheet for system-level design and validation.

Key Features

• Programmable Logic Capacity  Provides 242,000 logic elements to implement complex custom digital functions and wide parallel datapaths.
• Embedded Memory  Approximately 15.47 Mbits of on-chip RAM for buffering, FIFOs, and embedded data storage.
• I/O Resources  336 user I/Os to support high-density external interfacing and multi-channel connectivity.
• Package and Mounting  672-BBGA (FCBGA) supplier device package: 672-FBGA (27×27); surface-mount mounting type for board-level integration.
• Power Supply  Core supply voltage range from 1.07 V to 1.13 V to meet regulated power-rail requirements.
• Operating Grade and Temperature  Commercial-grade device with an operating temperature range of 0 °C to 85 °C.
• Standards Compliance  RoHS compliant.
• Comprehensive Documentation  Datasheet content for Arria V devices covers electrical characteristics, switching characteristics, configuration specifications, and I/O timing to support system design.

Typical Applications

• Custom Digital Logic  Implement custom datapaths, state machines, and protocol engines using the device’s 242,000 logic elements and embedded RAM.
• High-density I/O Systems  Leverage 336 I/Os for multi-channel interfaces, board interconnects, and sensor/actuator aggregation.
• Embedded Memory-Intensive Functions  Use approximately 15.47 Mbits of on-chip RAM for buffering, packet queues, and temporary data storage close to the logic.

Unique Advantages

• High logic density: 242,000 logic elements enable substantial on-chip integration of custom logic and parallel processing blocks, reducing external components.
• Significant embedded RAM: Approximately 15.47 Mbits of on-chip memory supports large buffers and local data handling without immediate external memory.
• Extensive I/O count: 336 user I/Os provide flexibility for dense board-level connectivity and multiple peripheral interfaces.
• Industry-standard package: 672-FBGA (27×27) surface-mount package simplifies placement in compact system layouts while supporting high pin-count connectivity.
• Commercial operating range: Rated for 0 °C to 85 °C operation and RoHS compliant for standard commercial production environments.
• Documented design guidance: The Arria V datasheet includes detailed electrical, switching, and configuration specifications to aid robust system integration.

Why Choose 5AGXMA7D4F27C5N?

The 5AGXMA7D4F27C5N Arria V GX FPGA delivers a balanced mix of programmable logic capacity, embedded memory, and extensive I/O in a commercially graded, RoHS-compliant package. Its combination of 242,000 logic elements, approximately 15.47 Mbits of RAM, and 336 I/Os makes it suitable for designs that require significant on-chip resources and dense external interfacing.

Engineers selecting this device benefit from the Arria V family documentation covering electrical characteristics, switching behavior, configuration, and I/O timing—providing the technical detail needed for system validation and deployment. This part is geared toward teams needing high integration density and well-documented device behavior for commercial applications.

Request a quote or submit an RFQ today to evaluate the 5AGXMA7D4F27C5N for your next FPGA-based design.
